  • Page 1 Built-in Oven User & installation manual NV75J3140RS / NV75J3140RW / NV75J3140BS NV75J3140BW / NV75J3140BB NV75J3140RS_EU_DG68-00618E-00_EN.indd 1 2015-02-05 4:02:02...

  • Page 2: Table Of Contents

    Contents Using this manual The following symbols are used in this User Manual: Safety instructions Important safety precautions Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Auto energy saving function Installation What’s included Power connection Cabinet mount Before you start Initial settings New oven smell Soft Closing Door (Gentle, Safe, and Silent)
  • Page 3 Cooking Smart Manual cooking Test Dishes Maintenance Cleaning Replacement Troubleshooting Checkpoints Information codes Appendix Product data sheet English 3 NV75J3140RS_EU_DG68-00618E-00_EN.indd 3 2015-02-05 4:02:02...

  • Page 4: Using This Manual

    Using this manual Thank you for choosing SAMSUNG Built-In Oven. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your oven and keep this book for future reference.

  • Page 5: Safety Instructions

    Safety instructions Installation of this oven must be performed only by a licensed electrician. The installer is responsible for connecting the appliance to the mains power supply in observance of the relevant safety recommendations. Important safety precautions WARNING This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for...
  • Page 6 Safety instructions Accessible parts may become hot during use. Young children should be kept away. If this appliance has steam or self cleaning function, excess spillage must be removed before cleaning and all utensils should not be left in the oven during steam cleaning or self cleaning. The cleaning function depends on the model.
  • Page 7 In the event of a fault or damage to the appliance, do not attempt to operate it. Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. If your oven needs repair, contact a SAMSUNG Service center or your dealer.
  • Page 8 Safety instructions When the cartridge is cracked or broken, do not use it and contact your nearest service center. (Vapour or steam function model only) This oven has been designed only for the cooking of household foods. During use, the oven interior surfaces become hot enough to cause burns. Do not touch heating elements or interior surfaces of the oven until they have had time to cool.

  • Page 9: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment)

    WARNING: Do not disconnect the appliance from the main power supply even after the cooking process is completed. WARNING: Do not leave the door open while oven is cooking. Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.

  • Page 10: Installation

    What’s included Make sure all parts and accessories are included in the product package. If you have a problem with the oven or accessories, contact a local Samsung customer centre or the retailer. Oven at a glance 01 Control panel...
  • Page 11 Accessories The oven comes with different accessories that help you prepare different types of food. Wire rack Wire rack insert * Baking tray * Universal tray * Extra-deep tray * Telescopic rail * NOTE Availability of accessories with an asterisk (*) depends on the oven model. English 11 NV75J3140RS_EU_DG68-00618E-00_EN.indd 11 2015-02-05...

  • Page 12: Power Connection

    If you use a plug-type socket, the plug must remain accessible after the oven is installed. Samsung is not responsible for accidents caused by missing or faulty earthgrounding. WARNING Do not step on or twist the wires during installation, and keep them away from heat- emitting parts of the oven.

  • Page 13: Cabinet Mount

    90 °C, and adjacent furniture must be resistant up to 75 °C. Samsung is not responsible for damage to furniture from the oven’s heat emission. The oven must be properly ventilated. For ventilation, leave a gap of about 50 mm between the lower shelf of the cabinet and the supporting wall.
  • Page 14 Installation Under-sink cabinet (mm) Min. 550 Min. 560 Min. 600 Min 460 x Min. 50 Mounting the oven Make sure to leave a gap (A) of at least 5 mm between the oven and each side of the cabinet. Secure at least 3 mm of gap (B) so that the door opens and closes smoothly.
  • Page 15 Fit the oven into the cabinet and fix the oven firmly on both sides using 2 screws. After installation is complete, remove the protective film, tape, and other packing material, and take out the provided accessories from inside the oven. To remove the oven from the cabinet, first disconnect power to the oven and remove 2 screws on both sides of the oven.

  • Page 16: Before You Start

    Before you start Initial settings When you power on the oven for the first time, the default time of “12:00” appears on the display where the hour element (“12”) blinks. Follow the steps below to set the current time. 1. Use the buttons to set the hour, and then press .

  • Page 17: Soft Closing Door (Gentle, Safe, And Silent)

    Soft Closing Door (Gentle, Safe, and Silent) The Samsung Built-in Oven features a soft closing door that gently, safely, and silently closes. When closing the door, the specially designed hinges catch the door a few centimetres before the final position. This is the perfect touch for added comfort, allowing the door to be closed silently and gently.
  • Page 18 Before you start Basic use For better cooking experience, familiarise yourself with how to use each accessory. Wire rack The wire rack is designed for grilling and roasting. Insert the wire rack into position with the protruding parts (stoppers on both sides) towards the front Wire rack insert * The wire rack insert is used with the tray, and prevents liquid...

  • Page 19: Operations

    Operations Control panel The front panel comes in a wide range of materials and colours. For improved quality, the actual appearance of the oven is subject to change without notice. 01 Mode dial Turn to select a cooking mode or function. 02 Cooking Time/ Press to set the cooking time.

  • Page 20: Fast Preheat

    Operations Fast preheat Optionally, you can fast preheat the oven. This will significantly shorten your waiting time until the preheating is done. To do this, follow the steps below. 1. Turn the mode dial to select 2. Turn the value dial to set a desired temperature within the temperature range.

  • Page 21: Cooking Modes

    Cooking modes It is recommended to insert food in the oven after preheating is complete. This will help obtain best result. 1. Turn the mode dial to choose a cooking mode. 2. Turn the value dial to set a desired temperature within the temperature range.

  • Page 22: To Stop Cooking

    Operations Suggested Mode Instructions temperature (°C) The bottom heating element generates heat, Bottom heat + which is evenly distributed by the convection convection fan. Use this mode for pizza, bread, or cake. The large-area grill emits heat. Use this mode Large grill for browning the tops of food (for example, Level 2...

  • Page 23: Convenience

    Convenience Oven light The oven light turns on automatically when the oven starts operation. To turn on the oven light without activating oven operations, simple turn the mode dial Child lock To prevent accidents, Child lock disables all controls. Hold down the buttons simultaneously for 3 seconds to activate, or hold down for 3 seconds again to deactivate...

  • Page 24: Cooking Smart

    Cooking Smart Manual cooking WARNING on acrylamide NOTE Acrylamide produced while baking starch- • Pre-heating is recommended for all contained food such as potato chips, French cooking modes unless otherwise specified fries, and bread may cause health problems. in the cooking guide. It is recommended to cook these foods at •...
  • Page 25 Type of Food Accessory Level Temp. (°C) Time (min.) heating Fruit crumble Wire rack, 22- 170-180 25-30 24 cm oven dish Scones Universal tray 180-190 30-35 Lasagne Wire rack, 22- 190-200 25-30 24 cm oven dish Universal tray 80-100 100-150 Meringues Soufflé...
  • Page 26 Cooking Smart Type of Food Accessory Level Temp. (°C) Time (min.) heating Pork roast, 1 kg Wire rack + 200-210 50-60 Universal tray Joint of pork, 1 Wire rack + 160-180 100-120 Universal tray Leg of lamb on Wire rack + 170-180 100-120 the bone, 1 kg...
  • Page 27 Grilling We recommend preheat the oven using large grill mode. Turn over after half of time. Type of Food Accessory Level Temp. (°C) Time (min.) heating Bread Toast Wire rack 270-300 Cheese toast Universal tray Beef Steak* Wire rack + 240-250 15-20 Universal tray...

  • Page 28: Test Dishes

    Cooking Smart Type of Food Accessory Level Temp. (°C) Time (min.) heating Frozen oven Universal tray 220-225 20-25 chips Frozen Universal tray 220-230 25-30 croquettes Test Dishes According to standard EN 60350-1 1. Baking The recommendations for baking refer to a preheated oven. Do not use the fast preheat function.
  • Page 29 Type of Temp. Time Type of food Accessory Level heating (°C) (min.) Apple pie Wire rack + 2 Spring 1 placed 160-180 70-80 form cake tins * (Dark diagonally coated, ø 20 cm) Universal tray + Wire 160-180 80-90 rack + 2 Spring form cake tins ** (Dark coated, ø...

  • Page 30: Maintenance

    Maintenance Cleaning Accessories WARNING Wash the accessories after every use, and • Make sure the oven and accessories are dry it with a tea towel. To remove stubborn cool before cleaning. impurities, soak the used accessories in • Do not use abrasive cleaning agents, warm soapy water for about 30 minutes hard brushes, scouring pads or cloths, before washing.
  • Page 31 Door Do not remove the oven door unless for cleaning purposes. To remove the door for cleaning, follow these instructions. WARNING The oven door is heavy. 1. Open the door and flip open the clips at both hinges. 2. Close the door approximately 70°. Hold the oven door by the sides using both hands, and lift and pull upwards until the hinges are removed.
  • Page 32 Maintenance Door glass Depending on the model, the oven door is equipped with 3-4 sheets of glass placed against each other. Do not remove the door glass unless for cleaning purposes. To remove the door glass for cleaning, follow these instructions. 1.
  • Page 33 6. When done, reinsert the sheets as follows: • Insert sheet 2 between support clip 1 and 2, and sheet 1 into support clip 3 in this order. 01 Support clip 1 02 Support clip 2 03 Support clip 3 7.
  • Page 34 WARNING If you encounter a water leak from the water collector, contact us at a local Samsung service center. 01 Water collector Ceiling (applicable models only) 1. Put down the grill heater. For this, turn the circular nut anticlockwise while holding the grill heater.
  • Page 35 Side runners (applicable models only) 1. Press the top line of the left side runner, and lower by approximately 45 º. 2. Pull and remove the bottom line of the left side runner. 3. Remove the right side runner in the same way.
  • Page 36 Maintenance Telescopic rails (applicable models only) 1. On the left Side runner, gently press the upper side of the rail to remove in the arrow direction. 2. Repeat the above step on the right Side runner to remove the right rail. 3.

  • Page 37: Replacement

    • Use only 25-40 W/220-240 V, 300 °C heat-resistant bulbs. You can purchase approved bulbs at a local Samsung service center. • Always use a dry cloth when handling a halogen bulb. This is to prevent the bulb from being tampered with fingerprints or sweat, resulting in a shortened lifecycle.

  • Page 38: Troubleshooting

    Troubleshooting Checkpoints If you encounter a problem with the oven, first check the table below and try the suggestions. If the problem continues, contact a local Samsung service centre. Problem Cause Action The buttons cannot be • If there is foreign matter •...
  • Page 39 Problem Cause Action The interior light is dim • If the lamp turns on and • The lamp automatically or does not turn on. then off turns off after a certain • If the lamp is covered amount of time to save by foreign matter during power.
  • Page 40 Troubleshooting Problem Cause Action Smoke comes out during • During initial operation • Smoke may come from operation. • If there is food on the the heater when you first heater use the oven. This is not a malfunction, and if you run the oven 2-3 times, it should stop happening.

  • Page 41: Information Codes

    Turn off the oven and try again. If C-d0 held for a period of time. the problem continues, contact a local Samsung service centre. Safety shutoff Oven has continued operating at a set This is not a system failure. Turn temperature for an extended time.

  • Page 42: Appendix

    Technical specifcations Appendix Product data sheet SAMSUNG SAMSUNG SAMSUNG SAMSUNG Model identification NV75J3140RS NV75J3140RW NV75J3140BS Energy Efficiency Index per cavity 102.3 102.3 102.3 (EEI cavity) Energy Efficiency Class per cavity Energy consumption required to 0.99 kWh/cycle 0.99 kWh/cycle 0.99 kWh/cycle...
  • Page 43 SAMSUNG SAMSUNG SAMSUNG Model identification NV75J3140BW NV75J3140BB Energy Efficiency Index per cavity (EEI cavity) 102.3 102.3 Energy Efficiency Class per cavity Energy consumption required to heat a 0.99 kWh/cycle 0.99 kWh/cycle standardised load in a cavity of an electric heated...
  • Page 44 70 70 19 70 www.samsung.com/dk/support FINLAND 030-6227 515 www.samsung.com/fi/support FRANCE 01 48 63 00 00 www.samsung.com/fr/support 0180 6 SAMSUNG bzw. 0180 6 7267864* GERMANY (*0,20 €/Anruf aus dem dt. Festnetz, aus dem www.samsung.com/de/support Mobilfunk max. 0,60 €/Anruf) ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support...
