To prevent accidents and/or machine
damage, read these instructions before
installation or use. Use the dryer only
as instructed in this owner's guide and
installation instructions manual included
with your dryer. Keep this guide for future
reference
Front-Loading Dryer
DHP 24400W
DHP 24412W
Owner's Guide & Installation Instructions
Advertisement
Chapters
Table of Contents
Related Manuals for Blomberg DHP 24400W
Summary of Contents for Blomberg DHP 24400W
- Page 1 Use the dryer only as instructed in this owner’s guide and installation instructions manual included with your dryer. Keep this guide for future reference Front-Loading Dryer DHP 24400W DHP 24412W Owner’s Guide & Installation Instructions...
- Page 2 Dear Customer, Thank you for prefering a Blomberg product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important Safety Instructions 5 Operating the product 5.1 Control panel ..........16 2 Your Dryer 5.2 Screen symbols ........16 2.1 Overview ..........8 5.3 Preparing the machine ......17 2.2 Package Contents ........9 5.4 Program selection ........17 5.5 Main programs ........17 3 Installation Instructions 5.6 Extra programs ........17 3.1 Electrical connection .......10... -
Page 4: Important Safety Instructions
Important Safety Instructions that you understand and have the WARNING: To reduce skills to carry out. the risk of fire, electric • Unplug the machine when it is shock, or personal not in use. injury when using • Never wash the appliance with this appliance, follow water! There is the risk of electric the basic precautions... - Page 5 WARNING: Improper • Adequate ventilation must connection of the be provided to avoid the back equipment-grounding flow of gases into the room from conductor can result appliances burning other fuels, in a risk of electric including open fires. shock. Check with a •...
- Page 6 to the tumble dryer can result if the • Keep pets away from the metal reinforcement come loose appliance during the drying cycle. during drying. • Before the appliance is removed • Before loading check all from service or discarded, remove garments for lighters, coins, metal the door to the drying compartment.
-
Page 7: Technical Specifications
