Draytek Vigor2960 Series Quick Start Quide page 25

S t e p 2
S t e p 2
After clicking Next, you can see the following page which will vary according to the IPv4
protocol type selected in Step 1.
For Static type, the page will be displayed as follows:
Available settings are explained as follows:
Item
IP Address
Subnet Mask
Gateway IP Address
DNS Server IP
Address
Description
Type the IP address of the router for the WAN profile.
Type the network mask of the router for the WAN profile.
Use the default setting (0.0.0.0). Such IP address is ready for
matching with the function of Virtual System.
Type a public IP address as the primary DNS (Domain Name
Server). To add a new IP address, simply Add. Four boxes
will appear for you to type the IP address. When you finish
the settings, click Save.
17
Vigor2960 Series Quick Start Guide
