- Page 1 Network Box Camera Installation Manual V3.0.0 Hangzhou Hikvision Digital Technology Co., Ltd. http://www.hikvision.com 2010-04...
- Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to DS-2CD883F-E(W),DS-2CD863PF(NF)-E(W), DS-2CD853F-E(W),DS-2CD854F-E(W),DS-2CD893PF(NF)-E(W), DS-2CD893PFWD(NFWD)-E(W) and DS-2CD833F-E(W) Network Camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
-
Page 3: Safety Instruction
7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 4 Installation Manual of Network Box Camera maintenance.) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
- Page 5 The average time varies because of differences between operating environment and usage history, so regular checking is recommended for all users. Please contact with your dealer for more details. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 6: Table Of Contents
2.2 Hardware Installation................7 Appendix Product Specification ..............9 DS-2CD883F-E(W)..................9 Specification....................9 Dimensions .................... 10 DS-2CD863PF(NF)-E(W) ................11 Specification..................11 Dimensions .................... 12 DS-2CD853F-E(W)..................13 Specification..................13 Dimensions .................... 14 DS-2CD854F-E(W)..................15 Specification..................15 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 7 Installation Manual of Network Box Camera Dimensions .................... 16 DS-2CD893PF(NF)-E(W)..................17 Specification ....................17 Dimensions .....................18 DS-2CD893PFWD(NFWD)-E(W) ...............19 Specification ....................19 Dimensions .....................20 DS-2CD833F-E(W) ....................21 Specification ....................21 Dimensions .....................22 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 8: Chapter 1 Introduction
This camera is ideal for remote control network applications. E.g.: 1. Network surveillance for supermarkets and factories. 2. Remote surveillance for homes and offices. 3. Indoor monitoring scenes, such as hotel, corridor, stairway. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 9: Chapter 2 Installation
Never attempt to disassemble the camera yourself. Users are responsible for any problem caused by modification or repairing without authorization. 2.1 Camera Description 2.1.1 Side Panel Description Side Panel 1: Side Panel 2: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 10 Damp+ Video Drive+ Drive- Auto iris interface with video driving uses three pins: Power, Video and GND; Auto iris interface with DC driving uses four pins: Damp+, Damp-, Drive+ and Drive-. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 11: Rear Panel Description
When the camera is power up, press the ‘RESET’ button for about 10 seconds, then all parameters, including user name, password, IP address, port number, etc., will be reset to the factory default settings. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 12: Camera Connection
Note: The alarm input is a NO/NC relay. If the input is not a NO/NC relay, follow the connection diagram below: To connect to an AC/DC load, use the following diagram: Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 13 The alarm output is an on/off output that requires external power supply on connection. The external power supply shall be 12V DC/30mA, or use AC with external relays. Equipment damage or electric shock may cause if without relays. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 14: Hardware Installation
Step 2: Screw the mounting hole to the mounting bracket, and then adjust the camera to the desired monitoring location and finally tighten the knob on bracket to secure the camera to the ceiling. Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 15 If required, loosen the knob on the mounting bracket and adjust the camera lens to the desired monitoring scene, and finally tighten the knob on bracket. Fig 2.2.3 Mount and adjust Lens Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
-
Page 16: Appendix Product Specification
Network Storage Support SD/SDHC, NAS (ISCSI optional) Intelligent Motion Detection, Video Loss, Network Broken, IP address Alarm conflict, Storage exception TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP Protocols (SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 17: Dimensions
DC12V±10% / PoE (AC24V optional) Power 5W MAX(10W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 18: Ds-2Cd863Pf(Nf)-E(W)
(SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password Basic Protection, watermark Interface Audio Input 1 channel microphone input, 3.5mm mini-jack Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 19: Dimensions
DC12V±10% / PoE (AC24V optional) Power 7.5W MAX(12.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 20: Ds-2Cd853F-E(W)
Motion Detection, Video Loss, Network Broken, IP address Alarm conflict, Storage exception TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP Protocols (SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) e-PTZ, Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Basic Password Protection, watermark Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 21: Dimensions
DC12V±10% / PoE (AC24V optional) Power 4.5W MAX(9.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 22: Ds-2Cd854F-E(W)
(SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password Basic Protection, watermark Interface Audio Input 1 channel microphone input, 3.5mm mini-jack Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω) Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 23: Dimensions
DC12V±10% / PoE (AC24V optional) Power 5.5W MAX(10.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 24: Ds-2Cd893Pf(Nf)-E(W)
Storage exception TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP Protocols (SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password Basic Protection, watermark Interface Audio Input 1 channel microphone input, 3.5mm mini-jack Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 25: Dimensions
DC12V±10% / PoE (AC24V optional) Power 5.5W MAX(10.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 26: Ds-2Cd893Pfwd(Nfwd)-E(W)
Motion Detection, Video Loss, Network Broken, IP address Alarm conflict, Storage exception TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP Protocols (SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional) Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password Basic Protection, watermark Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 27: Dimensions
DC12V±10% / PoE (AC24V optional) Power 5.5W MAX(10.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 28: Ds-2Cd833F-E(W)
Interface Audio Input 1 channel microphone input, 3.5mm mini-jack Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω) Communicati 1 RJ45 10M / 100M self-adaptive Ethernet interface and 1 RS-485 Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... -
Page 29: Dimensions
DC12V±10% / PoE (AC24V optional) Power 4.5W MAX(9.5W MAX with ICR Working) Consumption Dimensions(m 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”) Weight 500g (1.1lbs) *”W” series supports Wi-Fi (802.11g); Dimensions Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©... - Page 30 Installation Manual of Network Box Camera First Choice for Security Professionals Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©...
