Network Camera

Quick Operation Guide
V4.0.1
Hikvision Digital Technology Co., Ltd.
http://www.hikvision.com

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION DS-2CD883F-E

Summary of Contents for HIKVISION DS-2CD883F-E

  • Page 1: Network Camera

    Network Camera Quick Operation Guide V4.0.1 Hikvision Digital Technology Co., Ltd. http://www.hikvision.com...
  • Page 2 Dome camera IV DS-2CD7263NF(PF)-EZH, DS-2CD 7264FWD-EZH, DS-2CD7293PF(NF)-EIZH, DS-2CD7255F-EIZHS DS-2CD8253F-EI(Z), DS-2CD8233F-EI(Z), DS-2CD8264FWD-EI(Z), DS-2CD8264F-E, Bullet Camera DS-2CD8254F-EI, DS-2CD8254FWD-E, DS-2CD8283F-EI, DS-2CD8255F-EI Cube Camera I DS-2CD8133F-E, DS-2CD8153F-E Cube Camera II DS-2CD8464F-EI, DS-2CD8433F-EI Mini Dome Camera DS-2CD7164-E,DS-2CD7153-E, DS-2CD7133-E © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 3 UL MAKES NO REPRESENTATIONS, WARRANTIES CERTIFICATIONS WHATSOEVER REGARDING PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.” © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 4: Table Of Contents

    1.4.2 Cube Camera II .................... 15 1.5 Appearance Description of Mini Dome Camera ..........18 Chapter 2 Setting up the Network Camera over the LAN ........20 Chapter 3 Accessing via Web Browsers ..............23 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 5: Chapter 1 Appearance Description

    AUDIO OUT: Audio output interface SD: SD card slot VIDEO OUT: Video output interface Power supply interface PWR: Power LED indicator D+, D-: RS-485 interface Ground 1A, 1B: Alarm output interface © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 6: Box Camera Ii

    Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC. Camera wiring Diagram: Figure 1-3 Wiring Diagram 1.1.2 Box Camera II Camera description: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 7 VIDEO OUT/HDMI: Video output interface RESET: Reset button TXD, RXD, GND: RS-232 interface Power supply interface POWER: Power LED indicator SD: SD card slot AUDIO IN: Audio input interface AUDIO OUT: Audio output interface © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 8 Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC. Camera wiring Diagram: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 9: Box Camera Iii

    IN, G: Alarm input interface 1A, 1B: Alarm output interface Ground RESET: Reset button Notes:  After the powering on of the camera, pressing and holding the RESET button for about 10 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 10 Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC. Camera wiring Diagram: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 11: Appearance Description Of Dome Camera

    Alarm IN: Alarm input interface Alarm OUT: Alarm output interface AIN: Audio input interface AOUT: Audio output interface Power supply interface The function of positions 1-5 of DIP switch is shown below: Position Function © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 12: Dome Camera Ii

    AES: Auto Shutter AI: Auto Iris BLC: Back Light Compensation FL: Anti-flicker NAGC: Normal AGC SAGC: Special AGC Camera wiring Diagram: Figure 1-12 Wiring Diagram 1.2.2 Dome Camera II Camera description: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 13 AUDIO IN: Audio input interface AUDIO OUT: Audio output interface D+, D-: RS-485 interface IN, G: Alarm input interface 1A, 1B: Alarm output interface Power supply interface Camera wiring Diagram: Figure 1-14 Wiring Diagram © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 14: Dome Camera Iii

    Note: After the powering on of the camera, pressing and holding the INITIAL SET button for about 10 seconds can reset all the parameters to the default settings. Camera wiring Diagram: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 15 Quick Operation Guide of Network Camera Figure 1-16 Wiring Diagram © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 16: Dome Camera Iv

    PWR: Indicator is solid red when the device is powered on. Micro SD slot RESET: Reset button 10M/100M self-adaptive Ethernet interface Power supply interface Extended interface Notes:  The extended interface can be connected to alarm input/output interface, audio input/output © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 17: Appearance Description Of Bullet Camera

    Camera wiring Diagram: Figure 1-18 Wiring Diagram 1.3 Appearance Description of Bullet Camera Camera description: Figure 1-19 Overview Figure 1-20 Overview Table 1-11 Description Description © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 18: Appearance Description Of Cube Camera

    AUDIO IN, G: Audio input interface AUDIO OUT, G: Audio output interface Camera wiring Diagram: Figure 1-21 Wiring Diagram 1.4 Appearance Description of Cube Camera 1.4.1 Cube Camera I Camera description: Figure 1-22 Overview © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 19: Cube Camera Ii

    After the powering on of the camera, pressing and holding the RESET button for about 10 seconds can reset all the parameters to the default settings. Camera wiring Diagram: Figure 1-23 Wiring Diagram 1.4.2 Cube Camera II Camera description: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 20 10M / 100M self-adaptive Ethernet interface & PoE Note: After the powering on of the camera, pressing and holding the RESET button for about 10 seconds can reset all the parameters to the default settings. Camera wiring diagram: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 21 Quick Operation Guide of Network Camera Figure 1-25 Wiring Diagram © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 22: Appearance Description Of Mini Dome Camera

    RESET: Reset button. Note: After the powering on of the camera, pressing and holding the RESET button for about 10 seconds can reset all the parameters to the default settings. Camera wiring Diagram: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 23 Quick Operation Guide of Network Camera Figure 1-27 Wiring Diagram © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 24: Chapter 2 Setting Up The Network Camera Over The Lan

     Search active devices online Search online devices automatically: After launch the SADP software, it automatically searches the online devices every 15 seconds from the subnet where your computer locates. It displays the total number © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 25  Modify device information Steps: 1) Select the device to be modified in the device list and the network parameters of the © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 26  The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”.  For accessing the network camera from different subnets, please set the gateway for the network camera after you log in. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 27: Chapter 3 Accessing Via Web Browsers

    2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Input the user name and password. 4. Click © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 28 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in. Figure 3-3 Download Plug-in © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 29 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of network camera. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 30 First Choice for Security Professionals...
