Page 1: Network Camera
Network Camera Operation Guide UD.6L0201D0041A01... -
Page 2: About This Manual
Network Camera· Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Manual: This manual applies to DS-2CD883F-E(W), DS-2CD855F-E, DS-2CD854F(WD)-E(W), DS-2CD853F-E(W), DS-2CD864F(WD)-E(W), DS-2CD863PF(NF)-E(W), DS-2CD893PFWD(NFWD)-E(W), DS-2CD833F-E(W), DS-2CD893PF(NF)-E(W) series camera. -
Page 3: Regulatory Information
Network Camera· Quick Operation Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Network Camera· Quick Operation Guide 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
-
Page 5: Table Of Contents
Network Camera· Quick Operation Guide Contents 1 Appearance Description ..........5 1.1 Camera Description ..........5 1.2 Camera wiring diagram .........8 2 Installation ..............9 3 Setting the Network Camera over the LAN ....13 4 Accessing via WEB browser ......... 20... -
Page 6: Appearance Description
Network Camera· Quick Operation Guide 1 Appearance Description 1.1 Camera Description Figure 1-1 Overview Table 1-1 Description Description Lens mount Back Focus Ring SD card slot Auto-iris interface 10M/100M self-adaptive Ethernet interface... - Page 7 Network Camera· Quick Operation Guide VIDEO OUT: Video output interface AUDIO OUT: Audio output interface POWER: Power LED indicator Power supply interface MIC IN: Audio input interface D+, D-: RS-485 interface IN, G: Alarm input interface 1A, 1B: Alarm output interface Ground RESET: Reset button Notes:...
- Page 8 Network Camera· Quick Operation Guide Figure 1-2 Auto-iris Interface Table 1-2 Pins DC-driven Damp- Damp+ Drive+ Drive- Power, Video and GND pins are used when the auto-iris is driven by video; Damp+, Damp-, Drive+ and Drive- pins are used when the auto-iris is driven by DC.
-
Page 9: Camera Wiring Diagram
Network Camera· Quick Operation Guide 1.2 Camera wiring diagram Figure 1-3 Wiring Diagram... -
Page 10: Installation
Network Camera· Quick Operation Guide 2 Installation Before you start: Read the following contents carefully before the installation. Make sure that all the related equipment is power-off during the installation. Check whether the power supply is matched with your AC ... - Page 11 Network Camera· Quick Operation Guide Figure 2-1 Fix Camera Mounting Bracket Notes: For cement ceiling mounting, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket.
- Page 12 Network Camera· Quick Operation Guide Figure 2-2 Fix the Camera 3. Mount the camera lens. Connect the VIDEO OUT interface of the camera to the debugging monitor. Adjust the lens focus to obtain a perfect image on the monitor, and finally lock the lens. If required, loosen the knob on the mounting bracket and adjust the camera to the desired surveillance angle, and finally tighten the knob on bracket.
- Page 13 Network Camera· Quick Operation Guide Figure 2-3 Mount and Adjust Lens...
-
Page 14: Setting The Network Camera Over The Lan
Network Camera· Quick Operation Guide 3 Setting the Network Camera over the LAN Purpose: To view and configure the camera via LAN(Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or iVMS-4200 software to search and change the IP of network camera. - Page 15 Network Camera· Quick Operation Guide Use iVMS-4200 software and to list the online devices. Please refer to the user manual of client software for detailed information. 2. Change the IP address and subnet mask to the same subnet as of your PC.
-
Page 16: Search Online Devices Manually
Network Camera· Quick Operation Guide Figure 3-2 Searching Online Devices Note: Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online... - Page 17 Network Camera· Quick Operation Guide Note: You can click on each column heading to order the information; you can click to show the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.
- Page 18 Network Camera· Quick Operation Guide Figure 3-3 Select a device...
- Page 19 Network Camera· Quick Operation Guide Figure 3-4 Modify Network Parameters 3. Enter the IP address of network camera in the address field of the web browser to view the live video.
- Page 20 Network Camera· Quick Operation Guide Note: The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. For accessing the network camera from different subnets, please set the gateway for the network camera after you log in.
-
Page 21: Accessing Via Web Browser
Network Camera· Quick Operation Guide 4 Accessing via WEB browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple... - Page 22 Network Camera· Quick Operation Guide Figure 4-1 Adjust the Security Level Steps: 1. Open the web browser. 2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface.
- Page 23 Network Camera· Quick Operation Guide Figure 4-2 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
- Page 24 Network Camera· Quick Operation Guide Figure 4-3 Download Plug-in...
- Page 25 Network Camera· Quick Operation Guide Figure 4-4 Download Plug-in Figure 4-5 Install Plug-in...
- Page 26 Network Camera· Quick Operation Guide Figure 4-6 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of network camera.
- Page 27 Network Camera· Quick Operation Guide...
