INSTRUCTION MANUAL
Rotary Hammer
HR2230
007958
DOUBLE INSULATION
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading

Related Manuals for Makita HR2230

Summary of Contents for Makita HR2230

  • Page 1 INSTRUCTION MANUAL Rotary Hammer HR2230 007958 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    AC supply. They Authorized Representative in Europe: are double-insulated in accordance with European Makita International Europe Ltd. Standard and can, therefore, also be used from sockets Michigan Drive, Tongwell, Milton Keynes, Bucks MK15 without earth wire.

  • Page 3: General Safety Rules

    GEA001-3 reduce personal injuries. Avoid accidental starting. Ensure the switch is General Safety Rules in the off-position before plugging in. Carrying WARNING! Read all instructions. Failure to follow all power tools with your finger on the switch or instructions listed below may result in electric shock, fire plugging in power tools that have the switch on and/or serious injury.

  • Page 4: Specific Safety Rules

    of power tool, taking into account the working only when hand-held. conditions and the work to be performed. Use 12. Do not point the tool at any one in the area of the power tool for operations different from when operating. The bit could fly out and those intended could result in a hazardous injure someone seriously.

  • Page 5: Torque Limiter

    Reversing switch action Torque limiter The torque limiter will actuate when a certain torque 1. Reversing level is reached. The motor will disengage from the switch lever output shaft. When this happens, the bit will stop turning. CAUTION: As soon as the torque limiter actuates, switch off •...

  • Page 6: Depth Gauge

    Installing or removing the bit The depth gauge is convenient for drilling holes of uniform depth. Loosen the side grip and insert the depth 1. Bit shank gauge into the hole in the side grip. Adjust the depth 2. Bit grease gauge to the desired depth and tighten the side grip.

  • Page 7: Maintenance

    To maintain product SAFETY and RELIABILITY, repairs, carbon brush inspection and replacement, any other maintenance or adjustment should be performed by Makita Authorized Service Centers, always using Makita replacement parts. 007967 Use the optional drill chuck assembly . When installing it, refer to "Installing or removing drill bit"...
  • Page 8 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. SDS-Plus Carbide-tipped bits • Core bit • Diamond core bit •...
  • Page 12 Makita Corporation Anjo, Aichi, Japan 884703A228...
