Makita HP1501 Instruction Manual

15 mm (9/16”)
Hide thumbs Also See for HP1501:

Advertisement

Table of Contents

Hammer Drill
15 mm (9/16")
MODEL HP1501
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L
004187

Advertisement

Table of Contents
loading

Related Manuals for Makita HP1501

Summary of Contents for Makita HP1501

  • Page 1 Hammer Drill 15 mm (9/16”) MODEL HP1501 004187 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model HP1501 Concrete 15 mm (9/16”) Capacities Steel 13 mm (1/2”) Wood 25 mm (1”) No load speed (RPM) 0 - 2,800/min. Blows per minute 0 - 44,800 Overall length 299 mm (11-3/4”) Net weight 1.7 kg (3.7 lbs) •...
  • Page 3 trician to install a polarized outlet. Do not 13. Do not overreach. Keep proper footing change the plug in any way. Double insula- and balance at all times. Proper footing and balance enables better control of the tool in tion eliminates the need for the three wire unexpected situations.

  • Page 4: Specific Safety Rules

    22. Use only accessories that are recom- tenance performed by unqualified personnel mended by the manufacturer for your could result in a risk of injury. model. Accessories that may be suitable for 24. When servicing a tool, use only identical one tool, may become hazardous when used replacement parts.
  • Page 5 7. Some material contains chemicals which working dust inhalation and skin contact. may be toxic. Take caution to prevent Follow material supplier safety data. SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury.

  • Page 6: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Switch action 002455 CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released.
  • Page 7 Selecting the action mode 002420 This tool has an action mode changing button. For rotation with hammering, depress the button from the side with symbol fully. For rotation only, depress the button from the side with symbol fully. CAUTION: 1. Action mode changing button •...

  • Page 8: Depth Gauge

    Depth gauge 004189 The depth gauge is convenient for drilling holes of uniform depth. Loosen the side grip and insert the depth gauge into the hole in the side grip. Adjust the depth gauge to the desired depth and tighten the side grip. NOTE: •...

  • Page 9: Operation

    OPERATION Hammer drilling operation CAUTION: • There is a tremendous and sudden twisting force exerted on the tool/bit at the time of hole break-through, when the hole becomes clogged with chips and particles, or when striking reinforcing rods embedded in the concrete.

  • Page 10: Maintenance

    To maintain product SAFETY and RELIABILITY, repairs, car- bon brush inspection and replacement, any other mainte- nance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts.
  • Page 11 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 12 Memo...
  • Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
  • Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
  • Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...

  • Page 16: Warranty Policy

    WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
