Grizzly G5960 Instruction Manual

Collet closer for use with metal cutting lathe model g5960 and g7958
Hide thumbs
Table of Contents

Advertisement

Quick Links

COLLET CLOSER
MODEL G8143
INSTRUCTION MANUAL
FOR USE WITH METAL CUTTING LATHE MODEL G5960 AND G7958
COPYRIGHT © MAY, 2003 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN CHINA
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE
MACHINE CONFIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE
MACHINE, THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS
ABOUT DIFFERENCES. PREVIOUS VERSIONS ARE NOT AVAILABLE ONLINE.

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G5960

Summary of Contents for Grizzly G5960

  • Page 1 COLLET CLOSER MODEL G8143 INSTRUCTION MANUAL FOR USE WITH METAL CUTTING LATHE MODEL G5960 AND G7958 COPYRIGHT © MAY, 2003 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
  • Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
  • Page 3 NOTICE Safety Instructions For Metalworking Machines 1. READ AND UNDERSTAND MACHINE OWNERS MANUAL FOR YOUR LATHE. 2. REMOVE ADJUSTING WRENCHES. Form a habit of checking to see that keys and adjusting wrenches are removed from tool before turning on.
  • Page 4 Safety Instructions For Metalworking Tools 9. USE PROPER EXTENSION CORD. Make sure your extension cord is in good condi- tion. Conductor size should be in accor- dance with the chart below. The amperage rating should be listed on the motor or tool nameplate.

  • Page 5: Cover Removal

    G5860 or Model G7958 Metal-Cutting Lathe. The positive-locking handle clamps standard 5-C col- lets safely and securely for precision turning. Grizzly also offers an extensive line of precision- ground 5-C collets, ideal for use with the Model G8143 Collet Closer. See the latest Grizzly Catalog or visit our web site at www.grizzly.com...
  • Page 6 Figure 5. Make sure you have replaced the lathe cover! This pivot will allow the locking yoke to be secured to the lathe while providing a range of motion to engage the locking mechanism. The pivot connector should be secured tightly to the stud and the pivot pin should be in a horizontal position, allowing the pivot to move up and down.

  • Page 7: Tube Assembly

    To install the draw tube assembly into your lathe: Insert the draw tube assembly into the out- board spindle as shown in Figure 6. Slide the draw tube assembly all the way into the outboard spindle until it engages around the hub adapter.
  • Page 8 Locking Yoke To secure the locking yoke to your lathe: Align the connecting rod and locking yoke assembly onto the pivoting rod connector and secure them together with the 8mm cap screw as shown in Figure 9. Connecting Figure 9. Connecting rod and locking yoke installed on pivot connector.
  • Page 9 Make sure proper turning clearance exists between the bearing casing and the locking yoke before operation. Serious personal injury or damage to the lathe and collet closer can occur if there is contact. Rotate draw tube and check for clearance. DO NOT...
  • Page 10 (as viewed from the outboard end of the lathe in Figure 8). — If the draw tube fails to touch the collet, remove the collet and look into the spindle to see if the draw tube is accessible for proper engagement.

  • Page 11: Rough Adjustment

    Aftermarket Accessories 5-C collets do not come with the Model G4026 Collet Closer. However, they are available in the current Grizzly Catalog: • Model G1238 15 piece collet set, ranging in diameters from ⁄ " to 1".
  • Page 12 -10- G8143 Collet Closer...
  • Page 13 G8143 Collet Closer PART # DESCRIPTION PSS01M SETSCREW M6-1 X 10 P4026033 SPANNER NUT M30-1.25 W/ SS P4026009 DOGPOINT SETSCREW M8-1.25 X 38 P4026007 LOCKING YOKE PN03M HEX NUT M8-1.25 P4026034 SPANNER NUT M30-1.25 P6208 CARTRIDGE BALL BEARING 6208ZZ P4026023 BEARING SUPPORT P4026024 PN04M...

  • Page 14: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Imports, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, neg- ligence, accidents, repairs or alterations or lack of maintenance.

  • Page 15: Warranty Card

    The following information is given on a voluntary basis. This information will be used for marketing purposes to help Grizzly develop better products. Your name will be included in our mailing list only. It will not be sold to other com- panies.
  • Page 16 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here G8143 Collet Closer...

This manual is also suitable for:

G7958G8143
