Grizzly G7873 Parts Breakdown

REF PART # DESCRIPTION
1 PLW03M LOCK WASHER 6MM
2 PW03M FLAT WASHER 6MM
3 PB81M HEX BOLT M8-1.25 X 20 (LH)
4 PH7873004 LEFT COVER
5 PTS001M THUMB SCREW M6-1 X 16
6 PH7873006 LOWER BLADE GUIDE SUPPORT
7 PH7873007 LOWER CERAMIC GUIDE RING
8 PH7873008 LOWER ADJUST SHAFT
9 PH7873009 RIGHT COVER
10 PR05M EXT RETAINING RING 15MM
WARNING: NO PORTION Of THIS MANUAL MAy BE REPRODUCED IN ANy SHAPE
OR fORM WITHOUT THE WRITTEN APPROvAL Of GRIzzLy INDUSTRIAL, INC.
Copyright © AUgUSt, 2008 By grizzly indUStriAl, inC.
#tr11067 printed in tAiWAn
MODEL H7873
CERAMIC BLADE GUIDES
PARTS BREAKDOWN
REF PART # DESCRIPTION
11 P6202 BALL BEARING 6202ZZ
12 PH7873012 UPPER BLADE GUIDE SUPPORT
13 PH7873013 UPPER CERAMIC GUIDE RING
14 PTS001M THUMB SCREW M6-1 X 16
15 PB18M HEX BOLT M6-1 X 15
16 PH7873016 ADJUST BAR
17 PH7873017 UPPER SPACING SLEEVE
18 PH7873018 UPPER GUIDE SUPPORT BLOCK
19 PSS11M SET SCREW M6-1 X 16
