GE Security
1.1.1
I
NSTALLATION
Power: Ensure that the installation site's AC power is stable and within the rated
voltage of the external power supply. If the site's AC power is likely to have
spikes or dips, use power line conditioning or an Uninterruptible Power Supply.
Temperature: Observe the unit's ambient temperature specifications when
choosing a location for the unit. Extremes of heat or cold beyond the specified
operating temperature limits may cause the unit to fail. Do not install this unit on
top of other hot equipment.
Moisture: Do not expose the unit to rain or moisture. Moisture can damage
internal components. Do not install this unit near sources of water.
RS-232 Limitations: Cable length between the PC and ProBridge is limited to
50'. If the supplied cable is replaced by custom made cables to address
distances between components, ensure the cable is manufactured to ANSI
standards for RS-232 communication.
RS485 Limitations: If multiple RS485 devices are connected together, the
distance between the first and last device is limited to 3,000 feet (RS-485
communications).
1.2
P
OWER
The ProBridge is furnished with a power supply (110 or 240 VAC). Do not use
any other power supply with this product. The manufacturer accepts no
responsibility for damage caused by the use of any other power supply.
Make sure installation is complete and all connections are made before applying
power to the unit.
Voltage: 120 Volt AC
Tolerance: ±10%
Frequency: 60 Hz
Voltage: 12 Volt DC
Current: 110mA
Power: 1.3 Watts
Connector: 2.1mm female barrel. Center Positive
6
E
NVIRONMENT
4310-0007: 120VAC Power Supply
Power Supply Input
Power Supply Output
ProBridge Gateway
0150-0265C / April 2006
