Pro Bridge To Pc Cable; Pro Bridge To I/O Junction Box Or Cyber Domes - GE ProBridge User Manual

ProBridge Gateway
5.2 P B
RO RIDGE TO
Part Number : 4310-0047B
Communication Type: RS232
Connector Type: RJ-45, DB9F
Cable Required: 6 Foot RJ-45 to DB9F
RS232 Cable (Supplied). Connects
ProBridge to the serial port of a PC.
NOTE: This cable is used for Programming
ProBridge via HyperTerminal
RJ-45 Connector
5.3 P B
RO RIDGE TO
Part Number : 4310-0032A
Communication Type: RS485
Connector Type: RJ45, Flying Leads
Cable Required: RS-485 Flying Leads
Cable. Interconnects ProBridge with
KTD-405 and Dome Cameras.
RJ45 Connector
0150-0265C / April 2006
PC C
ABLE
Pin 8
Pin 7
Pin 6
Pin 5
Pin 4
Pin 3
Pin 2
Pin 1
RJ-45
Connector
I/O J
UNCTION
Connector
DB9F Connector
B C
OX OR YBER
Pin 8
Pin 7
Black
Pin 6
Pin 5
Pin 4
Red
Pin 3
Pin 2
Pin 1
RJ-45
Flying Leads
GE Security
Pin 9
Pin 8
Pin 7
Pin 6
Pin 5
Pin 4
Pin 3
Pin 2
Pin 1
DB-9F
Connector
D
OMES
Flying
Leads
11
