Memory Extender Board

The memory extender board is located directly under the front cover of the chassis. The standard
memory extender board can hold up to 16 DIMMs. The optional high capacity memory extender
board can hold up to 32 DIMMs.
WARNING!
from the server before removing or replacing a memory extender board.
Voltages are present at various locations within the server whenever an ac power source is
connected. This voltage is present even when the main power switch is in the off position.
Failure to observe this warning can result in personal injury or damage to equipment.
CAUTION:
follow ESD safety precautions can result in damage to the server.

Removing the Memory Extender Board

To remove a memory extender board, follow these steps:
1. If rack-mounted, slide the server out from the rack until it stops. See
Rack-Mounted Server" (page
NOTE:
the rack.
2. Remove the front bezel. See
3. Remove the front cover. See
4. Press the latches on the extraction levers located on each side of the memory extender board.
Figure 6-6 Memory Extender Board Latches
Ensure that the system is powered off and all power sources have been disconnected
Observe all ESD safety precautions before attempting this procedure. Failure to
149).
The memory extender board can be removed without removing the server from
"Removing the Front Bezel" (page
"Front and Top Covers" (page
"Accessing a
152).
152).
Memory Extender Board 155
