This product can be set up
using Internet Explorer 6.x
or above
Before You Begin
You must have at least the following:
• Windows 98/Me/2000/XP
• A CD-ROM drive
• An available Ethernet connection
Check Your Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DCS-3220.07292004
DCS-3220 2-Way Audio/Digital Zoom Internet Camera
CD-ROM with Manual and Software
CAT5 Ethernet Cable
Camera Stand
12V AC Power Adapter
DCS-3220
2-Way Audio/Digital Zoom
Internet Camera
Using a power supply
with a different voltage
rating will damage this
product and void the warranty.
Advertisement
Table of Contents
Related Manuals for D-Link DCS-3220
Summary of Contents for D-Link DCS-3220
-
Page 1: Internet Camera
12V AC Power Adapter rating will damage this product and void the warranty. ©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DCS-3220.07292004... -
Page 2: System Requirements
System Requirements • Internet Explorer 6.x or above • CPU: 1.7GHz or above • Memory Size: 128MB (256MB recommended) • VGA card resolution: 800x600 or above Note: If using multiple cameras for viewing/recording, the minimum requirements are a 2.4GHz or above CPU with 512MB memory and a 32MB video card. Hardware Installation Connect the Ethernet Cable Connect an Ethernet cable to the network cable connector... - Page 3 Hardware Installation (continued) Connect an Audio Cable Connect your speakers to the audio output jack on the back of the Internet Camera. For details on configuring the sound settings, please see the manual on the CD-ROM.
- Page 4 Installing the Installation Wizard Insert the DCS-3220 CD into the CD-ROM drive. Click on Install Software Click on Installation Wizard Click Next...
- Page 5 Installing the Installation Wizard (continued) Click Next Click Next Click Finish...
- Page 6 Configuring Your Camera with the Installation Wizard Double click on the Installation Wizard that was created on your desktop. The software will search for cameras. The Installation Wizard will appear show the MAC address of the DCS-3220 and an IP Address (which may or may not be correct depending on what you have your DCS-3220 connected to).
- Page 7 Configuring Your Camera with the Installation Wizard (continued) If the Installation Wizard does not display any devices, lightly insert a paper clip into the reset opening on the unit’s rear panel until the light starts to cycle (a series of blinks) twice, then let go.
- Page 8 Configuring Your Camera with the Installation Wizard (continued) Click the Setup button Enter an administrative password in the Root password and Confirm password fields. Click the Next button For details on the Date/Time Settings, please refer to the User Manual on the CD-ROM.
- Page 9 Configuring Your Camera with the Installation Wizard (continued) Uncheck the box labeled Reset IP address at next boot Click the Next button If you need to modify the IP settings, please refer to the user manual on the CD-ROM. Click the Apply button...
- Page 10 Configuring Your Camera with the Installation Wizard (continued) After the settings have been saved, the Done button will appear. Click the Done button Click the button labeled Link to Selected Device(s)
-
Page 11: Viewing Your Internet Camera
Viewing Your Internet Camera After you click the button labeled Link to Device(s), the Installation Wizard will automatically open your web browser to the IP address of the DCS-3220, in this example it is: http://192.168.0.120.Your DCS-3220 may have a different IP Address. - Page 12 Support echni cal Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product.
