How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Command or Action
Step 11
encapsulation aal0
Example:
Router(config-atm-l2trans-pvc)# encapsulation
aal0
Step 12
cbr pcr
Router(cfg-if-atm-l2trans-pvc)# cbr 1000
Step 13
service-policy output policy-map-name
Example:
Router(config-pmap-c)# service-policy output
out_cbr
Step 14
xconnect peer-router-id vcid encapsulation mpls
Example:
Router(config-atm-vc)# xconnect 2.2.2.2. 121
encapsulation mpls
Example
Router> enable
Router# configure terminal
Router(config)# policy-map out_cbr
Router(config-pmap)# class class-default
Router(config-pmap-c)# queue-limit 200 cells
Router(config-pmap-c)# exit
Router(config-pmap)# exit
Router(config)# interface atm1/0
Router(config)# atm clock internal
Router(config-if)# pvc 21/21 l2transport
Router(config-atm-l2trans-pvc)# encapsulation aal0
Router(cfg-if-atm-l2trans-pvc)# cbr 1000
Router(config-pmap-c)# service-policy output out_cbr
Router(config-atm-vc)# xconnect 2.2.2.2. 121 encapsulation mpls
Configuring Cell Relay over MPLS on PVPs
This task illustrates the configuration of UBR traffic shaping in cell relay over MPLS in VP mode.
SUMMARY STEPS
1.
2.
Cisco IOS Release 12.0(27)S
52
enable
configure terminal
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
For ATM Cell Relay, this command specifies raw cell
encapsulation for the interface. Make sure you specify the
same encapsulation type on the PE and CE routers.
Specifies CBR shaping.
The pcr value indicates the peak cell rate. The range is from
38 to 622,000 Kbps.
Note In place of the cbr command, you can use the ubr,
vbr-rt, or vbr-nrt commands to configure UBR,
VBR-rt, or VBR-nrt shaping in the same way.
Attaches the queue-limit service policy to the PVC.
Binds the attachment circuit to a pseudowire VC.
