Version 2.0 | 06/25/2014
User Manual
Fixed Dome Network Camera
DCS-6112/6113/6113V

Advertisement

Table of Contents
loading

Related Manuals for D-Link DCS-6113

Summary of Contents for D-Link DCS-6113

  • Page 1 Version 2.0 | 06/25/2014 User Manual Fixed Dome Network Camera DCS-6112/6113/6113V...
  • Page 2 Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description May 23, 2014 DCS-6112/6113/6113V Revision B1 Technical Specification version 1.0 2.00...

  • Page 3: Table Of Contents

    Device Settings ..............68 Video Settings ..............29 Time and Date ..............69 Image Settings ..............32 Maintenance ..............70 Audio Settings ..............34 Parameter List ..............72 *Day and Night Settings ..........35 * only applies to the DCS-6113 and 6113V. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 4 Logs ..................73 Appendix A - Technical Specifications ......74 Technical Specifications ............74 D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 5: Product Overview

    User Manual and Software on Quick Install Guide Fixed Dome CD-ROM Network Camera Power Adapter AV/Power Cable CAT5 Ethernet Cable Screw Driver Alignment Sticker If any of the above items are missing, please contact your reseller. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 6: System Requirements

    ƒ CPU: 1.7GHz or above (2.8GHz plus processor with 512MB memory and a 32MB video card is required for multiple camera viewing and recording in IP surveillance program) ƒ An available Ethernet connection D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 7: Introduction

    This industry leading technology coupled with H.264 compression, enables high-quality video footage to be recorded easily. The DCS-6112/6113/6113V connects to a network to provide high-quality live video over the Internet. The DCS-6113/6113V is capable of capturing video in both dark and light environments thanks to its built-in IR LEDs and IR-cut removable (ICR) filter. The ICR filter allows the camera to capture crisp color images during the daytime and detailed grayscale images at night or in or low-light conditions.

  • Page 8: Features

    New users will appreciate the convenient contextual help which offers an easy way to find assistance with camera management tasks. Reliable 24-Hour Surveillance DCS-6113 /6113V is equipped with infrared LED illuminators which provide a clear picture at night for dependable 24-hour surveillance. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 9: Hardware Overview

    Product Overview Hardware Overview Dome Cover Plastic housing (DCS-6112 and DCS-6113) Metal housing (DCS-6113V) Note: The DCS-6113V's Vandal-proof Housing will differ slightly from the image shown above. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 10 Light sensor Judges lighting conditions and switches from day mode to night mode accordingly Infrared LEDs (Control IR-LED and ICR on/off ) (DCS-6113 Used to illuminate the camera's field of view at and DCS-6113V only) night (DCS-6113 and DCS-6113V only) 3-Axis Mechanism Adjust the camera’s image to achieve...

  • Page 11: Hardware Installation

    5. The camera can be mounted with the cable routed through the ceiling, wall or from the side. 6. Insert the provided screws through the holes. Use a screwdriver to tighten and secure. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 12: Installation

    Connection with a PoE Switch If using a PoE switch, connect the network camera to the switch via an Ethernet cable, which will provide both power and data transmission over a single cable. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 13: Configuration With Wizard

    Insert the included CD into your computer's CD-ROM drive to begin the installation. If the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start automatically, click Start > Run. Type D:\autorun.exe, where D: represents the drive letter of your CD-ROM drive.
  • Page 14 Installation Click Yes to accept the License Agreement. To start the installation process, click Next. Note: The installation may take several minutes to finish. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 15 Installation Click Finish to complete the installation. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 16 Click the Wizard button to continue. Enter the Admin ID and password. When logging in for the first time, the default Admin ID is admin with the password left blank. Click Next, to proceed to the next page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 17 Select static IP if the camera will use the same IP address each time it is started. Click Next, to proceed to the next page. Take a moment to confirm your settings and click Restart. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 18: Web-Based Configuration Utility

    Installation Web-based Configuration Utility This section explains how to configure your new D-Link Network Camera using the Web-based Configuration Utility. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE Select the camera and click the button labeled "Link"...
  • Page 19 This section shows your camera’s live video. You can select your video profile and view or operate the camera. For additional information about web configuration, please refer to the user manual included on the CD-ROM or the D-Link website. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 20: Adjust The Viewing Angle

    3. Attach the dome cover to the camera as the direction shown below. With idiot-proof mechanism design, the dome cover cannot be attached if the angle does not fit. 4. Finally, make sure all parts of the camera are securely installed. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 21: Live Video

    When you connect to the camera's web interface you will see the following page. This is the Live Video page which will allow you to view the camera's video feed and control basic camera functions using the icons on the screen. Please refer to the tables on the following pages for detailed information about the icons on this screen. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 22 Configuration Click this logo to visit the D-Link website. D-Link Logo The logos and website can be customized to fit your needs. For more information, please refer to User Customization on page 64. Securicam Logo Setup the stream transmission mode and saving options on the local computer.
  • Page 23 Stop: Stop, Pan and Tilt. Select from the preset drop-down list to quickly move the camera to the desired preset position. Go Preset Control Pan/Tilt/Zoom speed Pan Speed Control Tilt Speed Control Zoom Speed Control Speed Control D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 24 50%: Keep the video zoom ratio at 50% Zoom ratio 25%: Keep the video zoom ratio at 25% Click the Help button to learn the detailed information regarding camera setup and solve any problems you encounter. Help D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 25: Client Setup

    Local Streaming Buffer Time Enter the buffer time in milliseconds. The buffer will cause a slight delay between live activity and the video of the live stream but may increase the quality of video. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 26: Setup

    Audio and Video - Video Settings, Audio Settings Network - IP Settings Event Management - Motion Detection, Tamper Detection PTZ Control - Digital PTZ System - User Settings, Device Settings, Time and Date, Maintenance D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 27: Advanced Setup

    Advanced setup includes the following options: System Overview Audio and Video - Video Settings, Image Settings, Audio Settings, *Day and Night Settings * function for DCS-6113/ DCS-6113V only Network - IP Settings, Port & Access Name Settings, Dynamic DNS, HTTPS, Access List, Advanced Settings...

  • Page 28: System Overview

    Configuration System Overview The system overview page contains a summary of the camera's current settings. For more information about adjusting these settings, please consult the subsequent instructions found in this manual. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 29: Video

    "Output Frame Rate" (size of the live view window). Stream 4: This is global view stream which captures the full view of the video. Users can also define the "Output Frame Rate" (size of the live view window). D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 30 Gain Control) setting. You can configure two sets of sensor setting: one for normal situations(Profile 1), the other for special situations, such as day/night/schedule mode(*Profile 2). * function for DCS-6113 and DCS-6113V only. Exposure • Maximum Exposure Time: Select a proper maximum exposure time according to the light source of the surroundings.
  • Page 31 • Fixed quality: To optimize the bandwidth utilization and video quality. The video quality can be adjusted to the following setting: Medium, Standard, Good, Detailed and Excellent. You can also select Customize and manually enter a value. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 32: Image Settings

    2. Place a sheet of white paper in front of the lens, then allow the camera to adjust the color temperature automatically. 3. Select Fixed to confirm the setting while the white balance is being measured. 4. Click Save to enable the new setting. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 33 • The "Sensor Settings" and "Image Settings" share the same *Profile 2 settings. * function for DCS-6113 and DCS-6113V only. Privacy Mask: In this page, you can block out certain sensitive zones for privacy concerns. To set up a Privacy Mask Window, follow the steps given below: 1.

  • Page 34: Audio Settings

    AAC bit rate: Select an AAC bit rate from the drop-down list. Higher bit rate means higher audio quality but it takes more network bandwidth to transmit. G.711: Select between uLAW (G.711) and ALAW (G.711) compression formats. A higher audio quality will require more bandwidth. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 35: Day And Night Settings

    Configuration *Day and Night Settings * Day & night function for DCS-6113 and DCS-6113V only. Switch to B/W in Night Mode: Select to automatically enable the camera to switch to B/W night mode. IR Cut Filter: The IR-Cut Removable (ICR) filter mechanically switches between two different sensor filters.

  • Page 36: Network

    Primary DNS: The Primary Domain Name Server (DNS) that translates hostname into IP address. Secondary DNS: Secondary Domain Name Server (DNS) that backups the Primary DNS. Primary WINS Server: The primary WINS server that maintains the database of computer name and IP address. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 37 (please refer to Media Settings). Select System log so that you will receive the system log in TXT file format which contains the camera’s public IP address in your e-mail or on the FTP server. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 38 3. Press Enter on the keyboard or click Refresh button to refresh the webpage. Manually Setup the IP Address: Select this option to manually configure IPv6 setting if your network environment does not have DHCPv6 server and advertisements-enabled routers. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 39: Port And Access Name Settings

    Network Camera For example, when the HTTP port is set to 80 and the secondary HTTP port is set to 8080. You can login camera as example link as below: Http://192.168.0.20 or Http://192.168.0.20:8080 D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 40 1 ~ 5> will fail to access the Network Camera. 2. Stream 5 is a special stream which users can only use URL commands to request the stream 5. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 41 When the multicast RTP port changes, the multicast RTCP port will change accordingly. Multicast TTL [1~255]: The multicast TTL (Time To Live) is the value that tells the router the range a packet can be forwarded. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 42: Dynamic Dns

    Username: Enter your username or e-mail used to connect to the DDNS Password: Enter your password used to connect to the DDNS server. Status: Indicate the connection status, automatically determined by the system. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 43: Https

    1. Click Create to open the Create Certificate page, then click Save to generate the certificate. 2. The Certificate Information will automatically be displayed in the third column as shown below. You can click Property to see detailed information about the certificate. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 44 If you want to create and install other certificates, please remove the existing one. To remove the signed certificate, deselect Enable HTTPS secure connection in the first column and click Save. Then click Remove to erase the certificate. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 45: Access List

    2. The administrator has set up a user password, but set RTSP Authentication to “disable“. • Refresh: Click this button to refresh all current connections. • Add to deny list: You can select entries from the Connection Status list D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 46 Always allow the IP address to access this device: You can select this item and add the Administrator’s IP address in this field to make sure the Administrator can always connect to the device. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 47: Advanced Settings

    • Authentication type: Select MD5 or SHA as the authentication method. • Authentication password: Enter the password for authentication (at least 8 characters). • Encryption password: Enter a password for encryption (at least 8 characters). D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 48 ƒ The ability to prioritize traffic and guarantee a certain level of performance to the data flow. ƒ The ability to control the amount of bandwidth each application may use, and thus provide higher reliability and stability on the network. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 49 Per Hop Behavior (PHB). The PHB describes a particular service level in terms of bandwidth, queuing theory, and dropping (discarding the packet) decisions. Routers at D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 50 Quality of service guarantees are important if the network capacity is insufficient, especially for real-time streaming multimedia applications. Quality can be defined as, for instance, a maintained level of bit rate, low latency, no packet dropping, etc. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 51: Event Management

    You can configure two sets of sensor setting: 4. Click Save to apply the changes. one for normal situations(Profile1), the other for special 5. Select Enable motion detection to activate motion detection. situations(Profile2), such as day/night/schedule mode. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 52: Tamper Detection

    Set up the event source as Camera Tampering Detection on Event Settings > Server Settings (how to send alarm message)/ Media Settings (send what type of alarm message)/Event Settings/. Please refer to Event settings for detailed information. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 53: Di And Do

    (DI+. GND) and digital output (DO-, +12V) that is used for connecting a diversity of external alarm devices to the camera such as IR-Sensors and alarm relays. Once triggered images will be taken and e-mailed. DI/DO Schematics D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 54: Event Settings

    To verify if the e-mail settings are correctly configured, click Test. The result will be shown in a pop-up window. If successful, you will also receive an e-mail indicating the result. Click Save to enable the settings, then click Close to exit the page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 55 To verify if the HTTP settings are correctly configured, click Test. The result will be shown in a pop-up window as below. If successful, you will receive a test.txt file on the HTTP server. Click Save to enable the settings then click Close to exit the page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 56 Add date and time suffix to the file name: Select this option to add a date/time suffix to the file name. Click Save to enable the settings, then click Close to exit the page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 57 System log: Select to send a system log when a trigger is activated. When completed, click Save to enable the settings and click Close to exit this page. The new media settings will appear on the Event Settings page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 58 Motion Detection Window first. For more information, please refer to Motion Detection for details. Periodically: This option allows the camera to trigger periodically for every other defined minute. Up to 999 minutes are allowed. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 59 (i.e. the server to send the media files to) when a trigger is activated. • Add Server: same as Server Settings • Add Media: same as Media Settings D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 60: Recording

    Capacity: You can choose either the entire free space available or limit the reserved space. The recording size limit must be larger than the reserved amount for cyclic recording. File name prefix: Enter the text that will be appended to the front of the file name. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 61 The new recording name will appear in the drop-down list on the recording page. To remove a recording setting from the list, select a recording name from the drop-down list and click Delete. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 62: Local Storage

    Search Results This area will show the search results. There are four columns: Trigger time, Media type, Trigger type, and Locked. Click up and down arrow to sort the search results in either direction. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 63: Ptz Control

    5. If you want to delete a selected location, select it from the Source list and click Remove. 6. Select a location and click Up or Down to rearrange the patrol order. 7. Click Save to enable the setting. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 64: User Customization

    5. The selected color will be displayed in the corresponding fields and in the Preview column. Click Save to enable the setting. DCS-6112B1 Title: You can also change the title at the top of your Live Video page. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 65: Html Code Examples

    MJPEG stream. Still Image Format: • Refresh interval second: If user only need to embedded still image in the browser, please use this option and setup the refresh interval of the still image. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 66: System

    Username: Enter a username for the new account. Password: Enter a password for the new account. Privilege: Select the access rights for the new user. Manage user: Manage the accounts for existing users. Authentication: The access rights for existing users. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 67: Device Settings

    Turn off the LED indicator: Select this option to turn off the LED next to the lens. This will prevent anyone from observing the operation of the network camera. Camera Name: Create a unique name for your camera. DCS-6112B1 D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 68: Time And Date

    Update Interval: The time interval for updating the time information from NTP server. Set the date and time manually: This option allows you to set the time and date manually. Copy Your Computer’s Time Setting: This will synchronize the time information from your PC. D-Link DCS-6112 /6113 / 6113V User Manual...

  • Page 69: Maintenance

    Notepad and locate your time zone. Set the ® start and end time of DST. 4. When completed, save the file Upload daylight saving time rule: Click Browse… and specify the XML file to upload. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 70 Note: Do not power off the camera during the upgrade! Follow the steps below to upgrade the firmware: 1. Download the latest firmware file from the D-Link website. The file is in .pkg file format. 2. Click Browse… and specify the firmware file.

  • Page 71: Parameter List

    Configuration Parameter List The Parameters List page lists the entire system’s parameters in alphabetical order. If you need technical assistance, please provide the information listed on this page. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 72 3. When completed, select Enable remote log and click Save to enable the setting. Current Log: This column displays the system log in chronological order. The system log is stored in the camera’s buffer area and will be overwritten when reaching a certain limit. D-Link DCS-6112 /6113 / 6113V User Manual...
  • Page 73 ƒ MPEG-4 AAC Network IPv4, IPv6, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP/HTTPS, Network Protocols Samba Client, PPPoE, UPnP Port Forwarding, RTP/RTSP/RTCP, IP filtering, LLTD, CoS/QoS, SNMP, IGMP, 802.1x Security ƒ...
  • Page 74 IK-10 standard (DCS-6113V) 466 g (1.03 lbs) (DCS-6112) Weight 472 g (1.04 lbs) (DCS-6113) 578 g (1.27 lbs) (DCS-6113V) Certifications CE (Class A), CE LVD (EN60965-1), FCC (Class A), ICES-003, C-Tick Dimensions DCS-6112, DCS-6113 DCS-6113V D-Link DCS-6112 /6113 / 6113V User Manual...
