- Page 1 USER MANUAL DCS-6112V /6113V VERSION 2.00...
-
Page 2: Manual Revisions
Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description November 09, 2011 DCS-6112V/6113V Revision A1 with firmware version 1.10 1.01... -
Page 3: Table Of Contents
System Overview ........... 30 User Settings ..........69 Video ..............31 Device Settings ..........70 Video Settings ..........31 Time and Date ..........71 Image Settings ..........34 Maintenance ..........72 Audio Settings ..........36 D-Link DCS-6112V /6113V User Manual... -
Page 4: D-Link Dcs-6112V /6113V User Manual
Parameter List ..........74 Logs .............. 75 Appendix A - Technical Specifications ....76 Technical Specifications ........76 D-Link DCS-6112V /6113V User Manual... -
Page 5: Product Overview
Quick Install Guide Full HD Vandal-proof Fixed on CD-ROM Dome Network Camera Power Adapter AV/Power Cable CAT5 Ethernet Cable Screw Driver Alignment Sticker If any of the above items are missing, please contact your reseller. D-Link DCS-6112V /6113V User Manual... -
Page 6: System Requirements
ƒ VGA card resolution: SVGA or XGA (1024x768 or above) ƒ CPU: 1.7GHz or above (2.8GHz plus processor with 512MB memory and a 32MB video card is required for multiple camera viewing and recording in IP surveillance program) ƒ An available Ethernet connection D-Link DCS-6112V /6113V User Manual... -
Page 7: Introduction
The built-in MicroSD card slot can be used as a local backup by storing important events on an easily retrievable MicroSD card. The included D-Link D-ViewCam™ is sophisticated software which allows users to manage up to 32 network cameras, set e-mail alert notifications, create recording schedules, and use motion detection to record directly to a hard drive. -
Page 8: Features
The DCS-6112V /6113V includes input and output ports for connectivity to external devices such as IR sensors, switches, and alarm relays. The DCS-6112V /6113V also incorporates Power over Ethernet (PoE), allowing it to be easily installed in a variety of locations without the need for supplemental power cabling. -
Page 9: Hardware Overview
Product Overview Hardware Overview Dome Cover Metal housing D-Link DCS-6112V /6113V User Manual... - Page 10 IR-LED and ICR on/off) (DCS-6113V only) 3-Axis Mechanism Adjust the camera’s image to Lens achieve the desired orientation Vari focal lens (DCS-6112V) / Fixed lens (DCS-6113V) Ethernet (PoE) MicroSD Card Slot RJ-45 connector for Ethernet which can also Local MicroSD card for storing...
-
Page 11: Hardware Installation
4.Insert the supplied plastic anchors into the drilled holes, and align the holes at the base of the camera with the plastic anchors. 5.The camera can be mounted with the cable routed through the ceiling, wall or from the side. 6.Insert the provided screws through the holes. Use a screwdriver to tighten and secure. D-Link DCS-6112V /6113V User Manual... -
Page 12: Installation
Connect the supplied power cable from the camera to a power outlet. Connection with a PoE Switch If using a PoE switch, connect the network camera to the switch via an Ethernet cable, which will provide both power and data transmission over a single cable. D-Link DCS-6112V /6113V User Manual... -
Page 13: Configuration With Wizard
Insert the DCS-6112V /6113V CD into your computer's CD-ROM drive to begin the installation. If the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start automatically, click Start > Run. Type D:\ autorun.exe, where D: represents the drive letter of your CD-ROM drive. - Page 14 Installation Click Yes to accept the License Agreement. To start the installation process, click Next. Note: The installation may take several minutes to finish. D-Link DCS-6112V /6113V User Manual...
- Page 15 Installation Click Finish to complete the installation. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE D-Link DCS-6112V /6113V User Manual...
- Page 16 Click the Wizard button to continue. Enter the Admin ID and password. When logging in for the first time, the default Admin ID is admin with the password left blank. Click Next, to proceed to the next page. D-Link DCS-6112V /6113V User Manual...
- Page 17 Select static IP if the camera will use the same IP address each time it is started. Click Next, to proceed to the next page. Take a moment to confirm your settings and click Restart. D-Link DCS-6112V /6113V User Manual...
-
Page 18: Web-Based Configuration Utility
Installation Web-based Configuration Utility This section explains how to configure your new D-Link Network Camera using the Web-based Configuration Utility. Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE Select the camera and click the button labeled "Link"... - Page 19 This section shows your camera’s live video. You can select your video profile and view or operate the camera. For additional information about web configuration, please refer to the user manual included on the CD-ROM or the D-Link website. D-Link DCS-6112V /6113V User Manual...
-
Page 20: Adjust The Viewing Angle
Loosen the focus controller and adjust the focus range by moving the controller left and right until the image is clear; tighten the focus controller once completed. D-Link DCS-6112V /6113V User Manual... -
Page 21: D-Viewcam Setup Wizard
D-ViewCam Setup Wizard D-ViewCam software is included for the administrator to manage multiple D-Link IP cameras remotely. You may use the software to configure all the advanced settings for your cameras. D-ViewCam is a comprehensive management tool for IP surveillance. - Page 22 Installation Click Finish to complete the installation. To start D-ViewCam, select Start > All Programs > D-Link D-ViewCam > Main Console. For more detail operation of using D-ViewCam software, please refer to D-ViewCam Manual. D-Link DCS-6112V /6113V User Manual...
-
Page 23: Configuration
Please refer to the tables on the following pages for detailed information about the icons on this screen. D-Link DCS-6112V /6113V User Manual... - Page 24 Configuration Click this logo to visit the D-Link website. D-Link Logo The logos and website can be customized to fit your needs. For more information, please refer to User Customization on page 67. Securicam Logo Setup the stream transmission mode and saving options on the local computer.
-
Page 25: Control Panel
Auto Pan: Auto Pan automatically scans an area horizontally. Select from the preset drop-down list to quickly move the camera to the desired preset position. Go Preset Control Pan/Tilt/Zoom speed Pan Speed Control Tilt Speed Control Zoom Speed Control Speed Control D-Link DCS-6112V /6113V User Manual... -
Page 26: Camera Control
50%: Keep the video zoom ratio at 50% Zoom ratio 25%: Keep the video zoom ratio at 25% Click the Help button to learn the detailed information regarding camera setup and solve any problems you encounter. Help D-Link DCS-6112V /6113V User Manual... -
Page 27: Client Setup
Local Streaming Buffer Time Enter the buffer time in milliseconds. The buffer will cause a slight delay between live activity and the video of the live stream but may increase the quality of video. D-Link DCS-6112V /6113V User Manual... -
Page 28: Setup
Configuration Setup The DCS-6112V /6113V includes basic and advanced setup screens. Both screens include a tree view with multiple setup options. This manual includes detailed explanations for all advanced setup screens. Basic Setup Click the setup button to enter the setup screen. -
Page 29: Advanced Setup
- Motion Detection, Tamper Detection, DI and DO, Event Settings Recording - Recording Settings, Local Storage PTZ Control - Digtal PTZ User Customization - Live Video Page Config, HTML Code Examples System - User Settings, Device Settings, Time and Date, Maintenance, Parameter List, Logs D-Link DCS-6112V /6113V User Manual... -
Page 30: System Overview
Configuration System Overview The system overview page contains a summary of the camera's current settings. For more information about adjusting these settings, please consult the subsequent instructions found in this manual. D-Link DCS-6112V /6113V User Manual... -
Page 31: Video
"Output Frame Rate" (size of the live view window). Stream 4: This is global view stream which captures the full view of the video. Users can also define the "Output Frame Rate" (size of the live view window). D-Link DCS-6112V /6113V User Manual... - Page 32 2. Select the applied mode: Day mode, Night mode, or schedule mode. Please manually enter a range of time if you choose Schedule mode. 3. Configure Exposure setting in the second column. 4. Click Save to enable the setting and click Close to exit the page. D-Link DCS-6112V /6113V User Manual...
- Page 33 • Fixed quality: To optimize the bandwidth utilization and video quality. The video quality can be adjusted to the following setting: Medium, Standard, Good, Detailed and Excellent. You can also select Customize and manually enter a value. D-Link DCS-6112V /6113V User Manual...
-
Page 34: Image Settings
2. Place a sheet of white paper in front of the lens, then allow the camera to adjust the color temperature automatically. 3. Select Fixed to confirm the setting while the white balance is being measured. 4. Click Save to enable the new setting. D-Link DCS-6112V /6113V User Manual... - Page 35 • Up to 5 privacy mask windows can be set up on the same screen. • If you want to delete the privacy mask window, please click the ‘x’ at the upper right-hand corner of the window. D-Link DCS-6112V /6113V User Manual...
-
Page 36: Audio Settings
(AMRNB) speech codec. Select a higher bit rate number for better audio quality. GSM-AMR bit rate: Select the GSM-AMR bit rate from the drop-down list. Higher bit rate means higher audio quality but it takes more network bandwidth to transmit. D-Link DCS-6112V /6113V User Manual... -
Page 37: Day And Night Settings
Light Sensor Sensitivity: Select Low, Normal, or High sensitivity for the light sensor. Disable IR LED: Select this box to disable the IR LED. The IR LED automatically switches on at night. By default the LED automatically switches on at night. D-Link DCS-6112V /6113V User Manual... -
Page 38: Network
Primary DNS: The Primary Domain Name Server (DNS) that translates hostname into IP address. Secondary DNS: Secondary Domain Name Server (DNS) that backups the Primary DNS. Primary WINS Server: The primary WINS server that maintains the database of computer name and IP address. D-Link DCS-6112V /6113V User Manual... - Page 39 (please refer to Media Settings). Select System log so that you will receive the system log in TXT file format which contains the camera’s public IP address in your e-mail or on the FTP server. D-Link DCS-6112V /6113V User Manual...
- Page 40 3. Press Enter on the keyboard or click Refresh button to refresh the webpage. Manually Setup the IP Address: Select this option to manually configure IPv6 setting if your network environment does not have DHCPv6 server and advertisements-enabled routers. D-Link DCS-6112V /6113V User Manual...
-
Page 41: Port And Access Name Settings
The FTP server allows the user to save recorded video clips. You can utilize D-Link's IP Cam Wizard to upgrade the firmware via FTP server. By default, the FTP port is set to 21. It also can be assigned to another port number between 1025 and 65535. - Page 42 1 ~ 5> will fail to access the Network Camera. 2. Stream 5 is a special stream which users can only use URL commands to request the stream 5. D-Link DCS-6112V /6113V User Manual...
- Page 43 RTCP port number is the multicast RTP port number plus one, and thus is always odd. When the multicast RTP port changes, the multicast RTCP port will change accordingly. Multicast TTL [1~255]: The multicast TTL (Time To Live) is the value that tells the router the range a packet can be forwarded. D-Link DCS-6112V /6113V User Manual...
-
Page 44: Dynamic Dns
Host Name: Enter the host name of the DDNS server. Username: Enter your username or e-mail used to connect to the DDNS Password: Enter your password used to connect to the DDNS server. Status: Indicate the connection status, automatically determined by the system. D-Link DCS-6112V /6113V User Manual... -
Page 45: Https
1. Click Create to open the Create Certificate page, then click Save to generate the certificate. 2. The Certificate Information will automatically be displayed in the third column as shown below. You can click Property to see detailed information about the certificate. D-Link DCS-6112V /6113V User Manual... - Page 46 If you want to create and install other certificates, please remove the existing one. To remove the signed certificate, deselect Enable HTTPS secure connection in the first column and click Save. Then click Remove to erase the certificate. D-Link DCS-6112V /6113V User Manual...
-
Page 47: Access List
User settings. 2. The administrator has set up a user password, but set RTSP Authentication to “disable“. For more information about RTSP Authentication, please refer to RTSP Streaming. D-Link DCS-6112V /6113V User Manual... - Page 48 Administrator IP address Always allow the IP address to access this device: You can select this item and add the Administrator’s IP address in this field to make sure the Administrator can always connect to the device. D-Link DCS-6112V /6113V User Manual...
-
Page 49: Advanced Settings
• Authentication type: Select MD5 or SHA as the authentication method. • Authentication password: Enter the password for authentication (at least 8 characters). • Encryption password: Enter a password for encryption (at least 8 characters). D-Link DCS-6112V /6113V User Manual... - Page 50 Quality can be defined as, for instance, a maintained level of bit rate, low latency, no packet dropping, etc. D-Link DCS-6112V /6113V User Manual...
- Page 51 CoS as "coarsely-grained" traffic control and QoS as "finely- grained" traffic control. • Though CoS is simple to manage, it lacks scalability and does not offer end-to-end guarantees since it is based on L2 protocol. D-Link DCS-6112V /6113V User Manual...
- Page 52 Quality of service guarantees are important if the network capacity is insufficient, especially for real-time streaming multimedia applications. Quality can be defined as, for instance, a maintained level of bit rate, low latency, no packet dropping, etc. D-Link DCS-6112V /6113V User Manual...
-
Page 53: Event Management
Sensitivity and Percentage slide bar. special situations(Profile2), such as day/night/ 4. Click Save to apply the changes. schedule mode. 5. Select Enable motion detection to activate motion detection. D-Link DCS-6112V /6113V User Manual... -
Page 54: Tamper Detection
Set up the event source as Camera Tampering Detection on Event Settings > Server Settings (how to send alarm message)/ Media Settings (send what type of alarm message)/Event Settings/. Please refer to Event settings for detailed information. D-Link DCS-6112V /6113V User Manual... -
Page 55: Di And Do
(DI+. GND) and digital output (DO-, +12V) that is used for connecting a diversity of external alarm devices to the camera such as IR-Sensors and alarm relays. Once triggered images will be taken and e-mailed. DI/DO Schematics D-Link DCS-6112V /6113V User Manual... -
Page 56: Event Settings
To verify if the e-mail settings are correctly configured, click Test. The result will be shown in a pop-up window. If successful, you will also receive an e-mail indicating the result. Click Save to enable the settings, then click Close to exit the page. D-Link DCS-6112V /6113V User Manual... - Page 57 Network storage: Select to send the media files to a network storage location when a trigger is activated. Click Save to enable the setting, then click Close to exit the page. When completed, the new server settings will automatically be displayed on the Event Settings page. D-Link DCS-6112V /6113V User Manual...
-
Page 58: Media Settings
Add date and time suffix to the file name: Select this option to add a date/ time suffix to the file name. Click Save to enable the settings, then click Close to exit the page. D-Link DCS-6112V /6113V User Manual... - Page 59 Click Save to enable the settings, then click Close to exit the page. When completed, click Save to enable the settings and click Close to exit this page. The new media settings will appear on the Event Settings page. D-Link DCS-6112V /6113V User Manual...
- Page 60 Detect next event after * seconds: Select the delay time before selecting the next event. It is being used for both events of motion detection and digital input trigger. D-Link DCS-6112V /6113V User Manual...
- Page 61 Camera tampering detection: This option allows the camera to trigger when the camera detects that it is being tampered with. To enable this function, you need to configure the Tamper detection option first. Please refer to Tamper detection for detailed information. D-Link DCS-6112V /6113V User Manual...
- Page 62 To set an event with recorded video or snapshots, it is necessary to configure the server and media setting so that the camera will know what action to take (i.e. the server to send the media files to) when a trigger is activated. • Add Server: same as Server Settings • Add Media: same as Media Settings D-Link DCS-6112V /6113V User Manual...
-
Page 63: Recording
Capacity: You can choose either the entire free space available or limit the reserved space. The recording size limit must be larger than the reserved amount for cyclic recording. File name prefix: Enter the text that will be appended to the front of the file name. D-Link DCS-6112V /6113V User Manual... - Page 64 Network Storage. The new recording name will appear in the drop-down list on the recording page. To remove a recording setting from the list, select a recording name from the drop-down list and click Delete. D-Link DCS-6112V /6113V User Manual...
-
Page 65: Local Storage
Search Results Window. Search Results This area will show the search results. There are four columns: Trigger time, Media type, Trigger type, and Locked. Click up and down arrow to sort the search results in either direction. D-Link DCS-6112V /6113V User Manual... -
Page 66: Ptz Control
5. If you want to delete a selected location, select it from the Source list and click Remove. 6. Select a location and click Up or Down to rearrange the patrol order. 7. Click Save to enable the setting. D-Link DCS-6112V /6113V User Manual... -
Page 67: User Customization
5. The selected color will be displayed in the corresponding fields and in the Preview column. Click Save to enable the setting. Title: You can also change the title at the top of your Live Video page. D-Link DCS-6112V /6113V User Manual... -
Page 68: Html Code Examples
MJPEG stream. Still Image Format: • Refresh interval second: If user only need to embedded still image in the browser, please use this option and setup the refresh interval of the still image. D-Link DCS-6112V /6113V User Manual... -
Page 69: System
Username: Enter a username for the new account. Password: Enter a password for the new account. Privilege: Select the access rights for the new user. Manage user: Manage the accounts for existing users. Authentication: The access rights for existing users. D-Link DCS-6112V /6113V User Manual... -
Page 70: Device Settings
Turn off the LED indicator: Select this option to turn off the LED next to the lens. This will prevent anyone from observing the operation of the network camera. Camera Name: Create a unique name for your camera. D-Link DCS-6112V /6113V User Manual... -
Page 71: Time And Date
Update Interval: The time interval for updating the time information from NTP server. Set the date and time manually: This option allows you to set the time and date manually. Copy Your Computer’s Time Setting: This will synchronize the time information from your PC. D-Link DCS-6112V /6113V User Manual... -
Page 72: Maintenance
Notepad and locate your time zone. Set the ® start and end time of DST. 4. When completed, save the file Upload daylight saving time rule: Click Browse… and specify the XML file to upload. D-Link DCS-6112V /6113V User Manual... - Page 73 Configuration Export language file: Click to export language strings. DCS-6112V /6113V provides 5 languages: English, Deutsch, Español, Français, Italiano. Upload custom language file: Click Browse… and specify your own custom language file to upload. Export setting backup file: Click to export all parameters for the device and user-defined scripts.
-
Page 74: Parameter List
Configuration Parameter List The Parameters List page lists the entire system’s parameters in alphabetical order. If you need technical assistance, please provide the information listed on this page. D-Link DCS-6112V /6113V User Manual... -
Page 75: Logs
3. When completed, select Enable remote log and click Save to enable the setting. Current Log: This column displays the system log in chronological order. The system log is stored in the camera’s buffer area and will be overwritten when reaching a certain limit. D-Link DCS-6112V /6113V User Manual... -
Page 76: Appendix A - Technical Specifications
ƒ MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps Network Network Protocols IPv4, IPv6, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP/HTTPS, Samba Client, PPPoE, UPnP Port Forwarding, RTP/RTSP/RTCP, IP filtering, 3GPP, LLTD, CoS/QoS, SNMP, IGMP, 802.1x Security ƒ... - Page 77 -20 to 70 ˚C (-4 to 158 ˚F) Vandal-proof IK-10 standard Humidity 90% non-condensing DCS-6112V: 572g (1.26 lbs) Weight DCS-6113V: 578g (1.27 lbs) Certifications CE (Class A), CE LVD (EN60965-1), FCC (Class A), ICES-003, C-Tick Dimensions 130mm 99.5mm D-Link DCS-6112V /6113V User Manual...
