Tracking Belt

The aim of tracking the belt is to keep it centered
on the rollers.
To track the belt:
1. Pre-track the belt according to Pre-Tracking
Belt on Page 28.
2. Tie back loose clothing and long hair to pro-
tect yourself from getting caught in the mov-
ing sanding belt when you start the machine.
3. Loosen the lock nut on the belt tracking knob.
4. Turn the sander ON, and using the tracking
control knob (see Figure 77), carefully adjust
the tracking in or out until the sanding belt is
centered on the main roller (see Figure 47,
Page 28).
Control Knob
Figure 77. Tracking control knob.
Note: The tracking control knob is very sen-
sitive; adjust it carefully in small increments.
Turning the knob clockwise moves the belt
toward the front of the sander.
5. Tighten the belt tracking knob lock nut.
Model G1014Z/G1014ZX (Mfd. Since 08/22)
Tracking
Changing Sanding
Disc
The model G1014Z/G1014ZX accepts 9" diameter
paper-backed pressure sensitive adhesive (PSA)
discs (refer to Accessories on Page 42).
To change the sanding disc:
1. DISCONNECT MACHINE FROM POWER!
2. Remove the work table and miter gauge.
3. Unscrew the pulley cover thumb knob, open
the cover, then remove the existing PSA
disc.
4.
Remove dried-on adhesive from the cast iron
disc with acetone or lacquer thinner and a
brush, then let it dry.
CAUTION: Follow the manufacturer's safety
recommendations when using acetone or
lacquer thinner.
5.
Peel off the backing from the new PSA disc,
then press it onto the cast iron plate, making
sure it contacts the surface evenly.
6.
Close the pulley cover, install the lock knob,
then install the work table and miter gauge.
-41-
