- Page 1 INSTRUCTION MANUAL Cordless Combination Hammer DHR182 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DHR182 Capacities Concrete 18 mm Core bit 35 mm Diamond core bit (dry type) 32 mm Steel 13 mm Wood 24 mm No load speed 0 - 1,350 min Blows per minute 0 - 5,000 min Overall length 301 mm Rated voltage D.C. -
Page 3: Ec Declaration Of Conformity
WARNING: Wear ear protection. WARNING: The noise emission during actual use of the power tool can differ from the declared value(s) depending on the ways in which the tool is used especially what kind of workpiece is processed. WARNING: Be sure to identify safety mea- sures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating... - Page 4 When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
- Page 5 Use power tools only with specifically desig- In cold weather or when the tool has not been nated battery packs. Use of any other battery used for a long time, let the tool warm up for packs may create a risk of injury and fire. a while by operating it under no load. This will loosen up the lubrication.
- Page 6 Doing so may causing fires, personal injury and damage. It will cause a malfunction of the wireless unit. also void the Makita warranty for the Makita tool and 18. Do not remove the sticker on the wireless unit. charger.
-
Page 7: Functional Description
Indicating the remaining battery FUNCTIONAL capacity DESCRIPTION Only for battery cartridges with the indicator CAUTION: Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge CAUTION: Always switch off the tool before... -
Page 8: Overheat Protection
Overheat protection NOTE: Use a dry cloth to wipe the dirt off the lens of the lamp. Be careful not to scratch the lens of lamp, or When the tool or battery is overheated, the tool stops it may lower the illumination. automatically. - Page 9 Rotation with hammering Adjusting the nozzle position of the dust collection system For drilling in concrete, masonry, etc., rotate the action mode changing knob to the symbol. Use a tungsten- Optional accessory carbide tipped bit (optional accessory). Push in the guide while pushing up the guide adjust- ment button, and then release the button at the desired position.
-
Page 10: Electronic Function
Torque limiter Installing or removing drill bit Clean the shank end of the drill bit and apply grease NOTICE: As soon as the torque limiter actuates, before installing the drill bit. switch off the tool immediately. This will help pre- vent premature wear of the tool. NOTICE: Drill bits such as hole saw, which tend to pinch or catch easily in the hole, are not appro-... -
Page 11: Depth Gauge
Chisel angle (when chipping, Installing or removing dust scaling or demolishing) collection system Optional accessory The chisel can be secured at the desired angle. To change the chisel angle, rotate the action mode chang- To remove the dust collection system, pull the tool while ing knob to the O symbol. Turn the chisel to the desired pressing the lock-off button. To install it, insert the tool angle. into the dust collection system all the way until it locks in place with a little click. - Page 12 Before installing the dust cup set, remove the bit from Dust cup set the tool if installed. Install the spacer so that the grooves on the Optional accessory spacer fit in the protrusions on the tool barrel while wid- Installing the dust cup set ening it. Be careful for the spring not to come off from the slit of spacer.
- Page 13 Removing the dust cup set Install the dust cup set so that the claws of the dust cup fit in in the slits on the spacer. To remove the dust cup set, follow the steps below. Loosen the side grip. ► 1 . Side grip ► 1 . Dust cup 2. Claws Hold the root of dust cup and pull it out. NOTE: If you connect a vacuum cleaner to the dust cup set, remove the dust cap before connecting it.
- Page 14 The tool hanger is intended for connecting the lanyard (tether strap). To install the tool hanger to the tool, follow the steps below. Remove the battery cartridge from the tool. Attach the tool hanger from the bottom of the tool as shown in the figure. Hook Optional accessory CAUTION: Always remove the battery when hanging the tool with the hook. CAUTION: Never hook the tool at high loca- tion or on potentially unstable surface. Insert the protrusion of the tool hanger into the groove on the left side of the tool.
-
Page 15: Operation
Tighten the screw firmly. Hammer drilling operation ► 1 . Screw CAUTION: There is tremendous and sudden twisting force exerted on the tool/drill bit at the time of OPERATION hole break-through, when the hole becomes clogged with chips and particles, or when striking reinforcing rods embedded in the concrete. Always use the side grip (auxiliary handle) and firmly hold the tool by CAUTION: Always use the side grip (auxiliary... - Page 16 Drilling in wood or metal Beating dust on the filter Optional accessory CAUTION: Hold the tool firmly and exert care when the drill bit begins to break through the CAUTION: Do not turn the dial on the dust workpiece. There is a tremendous force exerted on case while the dust case is removed from the the tool/drill bit at the time of hole break through.
- Page 17 Remove the dust case while pressing down the Blow-out bulb lever of the dust case. Optional accessory After drilling the hole, use the blow-out bulb to clean the dust out of the hole. ► 1 . Lever Open the cover of the dust case. Using dust cup set Optional accessory Fit the dust cup set against the ceiling when operating the tool.
- Page 18 16. In the event the tool is dropped, it must be • A vacuum cleaner which supports the wireless tagged and removed from service, and should activation function be inspected by a Makita Factory or Authorized The overview of the wireless activation function Service Center. setting is as follows. Refer to each section for detail procedures.
- Page 19 Tool registration for the vacuum ► 1 . Wireless unit 2. Projection 3. Lid 4. Recessed cleaner portion NOTE: A Makita vacuum cleaner supporting the wireless activation function is required for the tool registration. NOTE: Finish installing the wireless unit to the tool before starting the tool registration. NOTE: During the tool registration, do not pull the switch trigger or turn on the power switch on the vacuum cleaner.
- Page 20 If you wish to activate the vacuum cleaner along with NOTE: The wireless activation lamps finish blinking the switch operation of the tool, finish the tool registra- in green after 20 seconds elapsed. Press the wireless tion beforehand. activation button on the tool while the wireless acti- Install the batteries to the vacuum cleaner and the vation lamp on the cleaner is blinking.
- Page 21 Push the wireless activation button on the tool Pull the switch trigger of the tool. Check if the briefly. The wireless activation lamp will blink in blue. vacuum cleaner runs while the switch trigger is being pulled. To stop the wireless activation of the vacuum cleaner, push the wireless activation button on the tool. NOTE: The wireless activation lamp on the tool will stop blinking in blue when there is no operation for 2 hours.
- Page 22 Status Wireless activation lamp Description Color Duration Blinking Cancelling 20 seconds Ready for the cancellation of the tool registration. Waiting for the tool cancellation by the vacuum cleaner. registration 2 seconds The cancellation of the tool registration has been finished. The wireless activation lamp will start blinking in blue. Others 3 seconds The power is supplied to the wireless unit and the wireless activa-...
- Page 23 Troubleshooting for wireless activation function Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Makita Authorized Service Centers, always using Makita replace- ment parts for repairs. State of abnormality Probable cause (malfunction) Remedy The wireless activation lamp does The wireless unit is not installed into the tool. Install the wireless unit correctly. not light/blink. The wireless unit is improperly installed into the tool. The terminal of the wireless unit and/or Gently wipe off dust and dirt on the terminal of the the slot is dirty.
-
Page 24: Maintenance
Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. ► 1 . Filter 2. Filter case Replacing filter of dust case Attach a new filter to the filter case, and then attach the filter cover. Optional accessory... -
Page 25: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. - Page 28 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885674B222 www.makita.com 20181217...
