GE Senographe DS Manual page 390

GE Healthcare
Revision 1
Scenario PHY A001 - Physical Installation
Step
Connections
8 Remove Control Station front cover
9 Connect Gantry to Control Station
Connect Control Station to network
10 Clean IDC filter
11 If you did not have to separate the Genera-
tor and Gantry (see 4) remove the Genera-
tor covers to access the Generator
12 If you had to separate the Generator and
Gantry (see 4) then reconnect them
together
13 Connect HT cable
14 Connect AC supply to Generator
15 X-ray Console Cable Routing and connect
X-ray Console to Generator
16 Connect the Door safety switches and the
X-ray lamp to Generator
Completion
17 Optionally change mouse for trackball
18 Unpack/Install Radiation Screen
19 Opposite Side Rotative Arm Installation
20 Mount LCD monitor on Control Station
21 Install Bucky Support
22 Apply the regulatory and safety label as
required
Chapter 6
Service Information and Procedures Class A 2385072-16-8EN
Job Card
Job Card PHY A040 - Remove/Rein-
stall Control Station Covers on page
503
Job Card PHY A014 - Connect Gantry
to Control Station on page 455
Job Card PM A425 - IDC Air Filter
Cleaning on page 1803
Job Card PHY A042 - Remove/Rein-
stall Generator Covers on page 513
Generator Reconnection Procedure
on page 492 in Job Card PHY A030 -
Generator and Gantry Disconnection
Reconnection
Job Card PHY A015 - HT Cable Con-
nection on page 467
Job Card PHY A016 - AC Connection
on page 469
Job Card PHY A012 - X-ray Console
Cable Routing on page 451
Job Card PHY A018 - Room Lamps
and Door Configuration on page 475
Job Card PHY A011 - Trackball Option
Installation on page 443
Job Card PHY A004 - Radiation
Screen Installation on page 405
Job Card PHY A009 - Opposite Side
Rotative Arm Installation on page 415
Job Card PHY A010 - Mount LCD
Monitor on Control Station on page
435
Job Card PHY A005 - Bucky Support
Installation on page 409
Job Card PHY A006 - Regulatory and
Safety Labelling on page 411
Page no. 390
Senographe DS
Comments Done
Optional
Two
persons
required
Optional
SC-PHY-A-001.fm
