Operating Guide
Read this document when using the AK-HRP1015G Remote Operation Panel
in conjunction with AW-UE70 Series 4K Integrated Cameras or AW-HE35/
AW-HE38/AW-HE40/AW-HE70 Series HD Integrated Cameras.
For details of operating Remote Operation Panel AK-HRP1015G, please
visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
html), and refer to the Operating Instructions (HTML or PDF).
W0321AM0 -PS
Remote Operation Panel
AK-HRP1015G
Model No.
ENGLISH
DVQP2531ZA
Advertisement
Table of Contents
Related Manuals for Panasonic AK-HRP1015G
Summary of Contents for Panasonic AK-HRP1015G
- Page 1 Remote Operation Panel AK-HRP1015G Model No. Read this document when using the AK-HRP1015G Remote Operation Panel in conjunction with AW-UE70 Series 4K Integrated Cameras or AW-HE35/ AW-HE38/AW-HE40/AW-HE70 Series HD Integrated Cameras. For details of operating Remote Operation Panel AK-HRP1015G, please visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
-
Page 2: Table Of Contents
Table of Contents Connecting the Unit to AW-UE70/AW-HE35/AW- HE38/AW-HE40/AW-HE70 Series Cameras Connection examples Connections Compatible Functions List ROP Menu (when AW-UE70/AW-HE35/AW- HE38/AW-HE40/AW-HE70 is connected) ROP menu list 01 SCENE 02 SHUTTER SPEED 03 FILTER 04 CHROMA 05 GAIN 06 WHITE BALANCE 07 GAMMA 08 DETAIL 09 COLOR CORRECTION... -
Page 3: Connecting The Unit To Aw-Ue70/Aw-He35/Aw- He38/Aw-He40/Aw-He70 Series Cameras
Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras Connecting the Unit to AW-UE70/AW-HE35/AW- HE38/AW-HE40/AW-HE70 Series Cameras Connection examples Serial connection with AW-UE70 IP connection with AW-UE70 AW-UE70 AW-UE70 [LAN ACT/LINK] connector [RS-422] connector * Prepare a cable that is in accordance Supplied AC adapter Supplied AC adapter with the following serial connection... - Page 4 LAN cable (straight cable) PoE compatible switching hub or injector Switching hub with PoE support LAN cable (straight cable) Serial connection cable specifications AK-HRP1015G AW-UE70/AW-HE35/AW-HE38/ [CCU] connector side AW-HE40/AW-HE70 Pin No. Function Polarity Flow of signal [RS-422] connector side (RJ45)
-
Page 5: Connections
Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras Connections Set the connection setting to [Serial(AW3)] or [LAN(AW3)] in the [CONNECT SETTING] menu. NOTE To connect with the AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70, upgrade the system version of the unit to 2.00-00-0.00 or later. When connecting, observe the following points. Serial connection Use a dedicated cable to connect the [CCU] connector of this unit to the [RS-422] connector of the AW-UE70/AW- HE35/AW-HE38/AW-HE40/AW-HE70. -
Page 6: Compatible Functions List
Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras Compatible Functions List When the unit is used in conjunction with an AW-UE70 Series 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series HD Integrated Camera, there will be functions that are limited or disabled for some of the unit’s buttons, dials, and other controls. Be sure to refer to the following table. - Page 7 Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras ✓: Enabled Number Part name Remarks ×: Disabled ✓ [GAIN] button When this button is pressed, the gain menu appears on the LCD panel. The button is lit during menu display. ✓ [SHT] button When this button is pressed, the shutter menu appears on the LCD panel.
- Page 8 Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras ✓: Enabled Number Part name Remarks ×: Disabled ✓ [ALM] indicator [OPT] indicator × [EXT] indicator × ✓ [D.EXT] indicator ✓ Adjustment value display A value is also not displayed when [SHUTTER] is [SYNC]. The display will be bar display.
-
Page 9: Rop Menu (When Aw-Ue70/Aw-He35/Aw- He38/Aw-He40/Aw-He70 Is Connected)
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW- HE40/AW-HE70 is connected) ROP menu list When an AW-UE70 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-HE70 HD Integrated Camera is connected, the ROP menu will be as follows. For details on menu operations, refer to the following sections in the Operating Instructions. “Displaying menus”... - Page 10 ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) “TYPE” (see page 22) TYPE COLOR CORRECT “COLOR CORRECT” (see page 22) “SAT” (see page 22) PHASE “PHASE” (see page 22) “SAT B” (see page 22) SAT B “PHASE B” (see page 22) PHASE B “SAT B_B_Mg”...
- Page 11 ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) SENSE Refer to the following section in the Operating Instructions. “29 IRIS RELATIVE” 13 IRIS RELATIVE COARSE RELATIVE FORMAT “FORMAT” (see page 28) “FREQUENCY” (see page 28) FREQUENCY “I.S.” (see page 28) I.S. “BARS TYPE” (see page 28) BARS TYPE “OSD STATUS”...
- Page 12 ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) ROP IP ADDRESS 1 Refer to the following section in the Operating Instructions. “39 ROP IP SETTING” ROP IP ADDRESS 2 ROP IP ADDRESS 3 ROP IP ADDRESS 4 PORT UPLOAD ROP SUBNET MASK 1 ROP SUBNET MASK 2 18 ROP IP SETTING ROP SUBNET MASK 3...
-
Page 13: Scene
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 01 SCENE Item Setting details MANUAL1(push) Selects a scene file. When a scene file is set to ON, the other scene files will be set to OFF. MANUAL2(push) MANUAL3(push) FULL AUTO(push) - 13 -... -
Page 14: Shutter Speed
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 02 SHUTTER SPEED Item Setting details MODE Selects the operation mode of the shutter. SPEED Sets the shutter speed. The setting can be changed when [MODE] is [STEP]. The shutter speed of [SYNC] is not displayed. - 14 -... -
Page 15: Filter
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 03 FILTER Item Setting details Sets the ND filter position. - 15 -... -
Page 16: Chroma
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 04 CHROMA Item Setting details LEVEL Sets the color intensity of images. - 16 -... -
Page 17: Gain
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 05 GAIN Item Setting details GAIN Adjusts the gain of images. AGC MAX GAIN When [AUTO] is selected as the [GAIN] setting, the maximum gain-up amount can be set. - 17 -... -
Page 18: White Balance
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 06 WHITE BALANCE Item Setting details MODE Sets the white balance mode. COLOR TEMP Sets color temperature settings. GAIN R Adjusts the R gain. GAIN B Adjusts the B gain. - 18 -... -
Page 19: Gamma
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 07 GAMMA Item Setting details TYPE Selects the type of gamma curve. LEVEL Adjusts the gamma correction level. Sets the DRS function which performs correction when video with high light/dark contrast is displayed. - 19 -... -
Page 20: Detail
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 08 DETAIL Item Setting details Adjusts the image contour (i.e., image sharpness). LEVEL H Adjusts the contour correction level when [DTL] is set to [HIGH]. LEVEL L Adjusts the contour correction level when [DTL] is set to [LOW]. FLESH TONE MD Sets flesh tone mode to make the skin of subjects appear smoother and more attractive. -
Page 21: Color Correction
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 09 COLOR CORRECTION - 21 -... - Page 22 ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) Item Setting details TYPE Selects the type of color matrix. COLOR CORRECT Selects the color component in 12-axis matrix memory to adjust. Adjusts the saturation of the color component selected in [COLOR CORRECT]. PHASE Adjusts the hue of the color component selected in [COLOR CORRECT].
- Page 23 ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) Item Setting details SAT Mg_R Adjusts the color saturation between magenta and red. PHASE Mg_R Adjusts the hue between magenta and red. SAT R Adjusts red color saturation. PHASE R Adjusts red hue. SAT R_R_Yl Adjusts the color saturation with a 3:1 red to yellow ratio.
-
Page 24: Dnr
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 10 DNR Item Setting details Sets the level for the noise reduction. - 24 -... -
Page 25: Contrast
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 11 CONTRAST Item Setting details CONTRAST MODE Selects auto/manual for image brightness (contrast) control. CONTRAST LEVEL Sets the convergence level for adjusting image brightness. FRAME MIX Selects for frame addition (gain-up using sensor storage) amount. A.F.MIX MAX GAIN Sets the maximum amount of frame addition for when [AUTO] is selected in [CONTRAST MODE] or [AUTO] is selected in [FRAME MIX]. -
Page 26: Lens Control
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 12 LENS CONTROL Item Setting details FOCUS MODE Selects auto or manual mode for the focus adjustment function. FOCUS SPEED Adjusts the focus operation speed. FOCUS Adjusts the lens focus manually. ZOOM WIDE Adjusts the lens zoom to wide angle (Wide). ZOOM SPEED Adjusts the zoom operation speed. -
Page 27: Iris Relative
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 13 IRIS RELATIVE For details on operations and settings, refer to the following sections in the Operating Instructions. “29 IRIS RELATIVE” - 27 -... -
Page 28: System Cam
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 14 SYSTEM CAM Item Setting details FORMAT Displays the system format. FREQUENCY Displays the frame frequency. I.S. Select the image stabilization mode. When connected with AW-HE35/AW-HE38/AW-HE40/AW-HE70 series cameras, both the [MODE1] and [MODE2] selection parameters are treated as [ON] on the camera side. BARS TYPE Changes the type of color bar to display. -
Page 29: Camera Menu Control
ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected) 15 CAMERA MENU CONTROL Item Setting details MENU ON/OFF Turns the menu on or off. CURSOR/PARAMETER Moves the menu cursor or changes setting values. EXECUTE Executes the selected process. - 29 -... -
