Grizzly T26979 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The T26979 3-in-1 Workpiece Support Stand will
support up to 250 lbs. It is adjustable from 27
to 43". The stand has a small footprint of 22" X
18". The stand has three positions: static, multi-
directional, and single plane.
Lock
Lever
Leveling
Dial
Figure 1. Model T26979 controls and
components.
Setup
Push lock knob to release leg, then extend leg
until it locks in open position.
Adjusting Height
1.
Turn lock lever counterclockwise to adjust
head to needed height.
2. Turn lock lever clockwise to secure head in
place.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
Three-Position
Head
Lock
Knob
COPYRIGHT © JANUARY 2015 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 06/14) #AW17097 PRINTED IN CHINA
MODEL T26979
3-IN-1 WORKPIECE
SUPPORT STAND
Adjusting Head
Lift up on head to disengage pivot stop, then
rotate head into positive stop at desired position.
⁄ "
1
2
Positive stop does not allow further movement.
(see Figure 2).
Note: To prevent pinching, use two hands and lift
from outside of head.
Static
Figure 2. Three head positions.
Collapsing Legs
Push lock knob towards stand, then slide legs
towards each other to lock.
INSTRUCTIONS
Multi-Directional
Single Plane
V1.01.15
