- Page 1 INSTRUCTION MANUAL Dustless Cutter 4100KB DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: 4100KB Wheel diameter 125 mm Max. wheel thickness 2.2 mm Max. cutting capacities 40 mm Rated speed (n) 12,200 min Overall length 231 mm Net weight 3.0 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. • Specifications may differ from country to country. • Weight according to EPTA-Procedure 01/2014... -
Page 3: Ec Declaration Of Conformity
Use of power supply via an RCD with a rated EC Declaration of Conformity residual current of 30 mA or less is always recommended. For European countries only Power tools can produce electromagnetic The EC declaration of conformity is included as Annex A fields (EMF) that are not harmful to the user. - Page 4 Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Follow instruction for lubricating and chang- ing accessories. Cutter safety warnings The guard provided with the tool must be securely attached to the power tool and positioned for maximum safety, so the least amount of wheel is exposed towards the oper-...
- Page 5 10. Keep bystanders a safe distance away from Use special care when working corners, sharp work area. Anyone entering the work area edges etc. Avoid bouncing and snagging the must wear personal protective equipment. accessory. Corners, sharp edges or bouncing Fragments of workpiece or of a broken wheel may have a tendency to snag the rotating accessory fly away and cause injury beyond immediate area...
-
Page 6: Functional Description
NEVER use the tool if it runs when you simply pull the switch trigger without press- ing the lock-off button. A switch in need of repair may result in unintentional operation and serious personal injury. Return tool to a Makita service center for proper repairs BEFORE further usage. WARNING: NEVER defeat the lock-off button by taping down or some other means. - Page 7 Slipping your hand from the hex onto the dust spout. wrench can cause a personal injury. CAUTION: Use only the Makita wrench and hex wrench to install or remove the wheel. Hold the outer flange with the wrench and loosen the hex bolt with the hex wrench. Then remove the hex bolt, outer flange and diamond wheel.
-
Page 8: Operation
► 1 . Fastener Connecting the vacuum cleaner When you wish to perform clean cutting operation, connect a Makita vacuum cleaner to your tool. MAINTENANCE CAUTION: Always be sure that the tool is switched off and unplugged before attempting to perform inspection or maintenance. -
Page 9: Replacing Carbon Brushes
Both carbon brushes should be replaced at the CAUTION: These accessories or attachments same time. Use only identical carbon brushes. are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 12 Jan-Baptist Vinkstraat 2, Makita Europe N.V. 3070 Kortenberg, Belgium 3-11-8, Sumiyoshi-cho, Makita Corporation Anjo, Aichi 446-8502 Japan 885607A227 www.makita.com 20170904...
