MODEL G0632Z
16" X 42" VARIABLE-
SPEED WOOD LATHE
MANUAL INSERT
The Model G0632Z is the same machine as the Model G0632 except it has a higher full-load current rat-
ing, a different inverter and inverter cover, a hinged front belt access cover, and a tool holder on the stand.
Except for the differences noted in this insert, all other content in the Model G0632 owner's manual applies
to this machine.
: To reduce the risk of serious injury, you MUST read and understand this insert—and
the entire Model G0632 manual—BEFORE assembling, installing, or operating this machine!
If you have any further questions about this manual insert or the differences between the Model G0632 and
the Model G0632Z, contact our Technical Support at (570) 546-9663 or email techsupport@grizzly.com.
COPYRIGHT © APRIL, 2017 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MANUFACTURED SINCE 01/17) #KB18890 PRINTED IN CHINA
Advertisement
Related Manuals for Grizzly G0632Z
Summary of Contents for Grizzly G0632Z
- Page 1 MANUAL INSERT The Model G0632Z is the same machine as the Model G0632 except it has a higher full-load current rat- ing, a different inverter and inverter cover, a hinged front belt access cover, and a tool holder on the stand.
- Page 2 Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0632Z 16" X 42" VARIABLE-SPEED WOOD LATHE Product Dimensions: Weight ................................... 386 lbs. Width (side-to-side) x Depth (front-to-back) x Height ................77-1/2 x 22-1/2 x 47 in.
- Page 3 Hex Wrenches Indexing Pin Knock-Out Tool Spur Center Model G0632Z (Mfd. Since 01/17) The information contained herein is deemed accurate as of 4/6/2017 and represents our most recent product specifications. Page 2 of 2 Model G0632Z Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
- Page 4 New Parts The Model G0632Z features a convenient tool The Model G0632Z uses an ATV-13 variable- holder attached to the stand (see Figure 1). frequency inverter to control motor speed. The inverter cover features a removable side panel that encloses the power cords and (3) Type-3 M20-1.5 strain-relief connectors (see Figure 3).
-
Page 5: Electrical Components
RPM Readout REV/FWD & Circuit Board Switch Figure 4. Control panel wiring (shown from the back of the panel). Figure 6. RPM sensor wiring. Figure 5. Motor junction box wiring. Figure 7. Frequency inverter wiring. Model G0632Z (Mfd. Since 01/17) -
Page 6: Wiring Diagram
6-15 Plug (As Recommended) WARNING! SHOCK HAZARD! Disconnect power before working on wiring. Motor 220V 3-Phase RPM Sensor Control Panel Ground RPM Readout Variable-Speed REV/FWD Emergency & Circuit Board Control Switch Stop (Viewed from Behind) Model G0632Z (Mfd. Since 01/17) - Page 7 MACHINE FOOT M10-1.5 X 60 P0632Z013 TAILSTOCK LOCK BRACKET P0632Z029 HANDWHEEL HANDLE 9 X 20, M8-1.25 X 10 P0632Z014 BUSHING P0632Z030 TOOL HOLDER P0632Z015 LEADSCREW P0632Z082 CAP SCREW M5-.8 X 16 P0632Z016 TAILSTOCK LOCK LEVER Model G0632Z (Mfd. Since 01/17)
- Page 8 Headstock 113 114 61-3 61-7 61-6 61-1 61-5 61-2 61-4 61-9 61-8 Model G0632Z (Mfd. Since 01/17)
- Page 9 P0632Z068 FLAT WASHER 10MM 133 P0632Z133 PHLP HD SCR M4-.7 X 6 P0632Z069 MOTOR MOUNTING PLATE 134 P0632Z134 PHLP HD SCR M4-.7 X 10 P0632Z070 KNOB M8-1.25 135 P0632Z135 PHLP HD SCR M6-1 X 12 Model G0632Z (Mfd. Since 01/17)
- Page 10 P0632Z203 ENTANGLEMENT WARNING LABEL P0632Z209 DISCONNECT POWER LABEL P0632Z204 IMPACT INJURY WARNING LABEL P0632Z210 FACE/LUNG WARNING LABEL P0632Z205 READ MANUAL LABEL P0632Z211 SPINDLE SPEED LABEL P0632Z206 MACHINE ID LABEL P0632Z212 TOUCH-UP PAINT GRIZZLY GREEN -10- Model G0632Z (Mfd. Since 01/17)
- Page 11 Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from WARRANTY & RETURNS the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
