Baratza Sette 270 Quick Start Manual

®
Sette™ 270
Remove the grinder, bin, power cord, and bean hopper from
the box. Install lid onto bean hopper. With the shutoff knob
facing the 11 o'clock position, line up the 3 hopper tabs
with the slots in the top of the grinder. Set the hopper in
place and rotate firmly clockwise until the hopper clicks into
place. Note: Grinder motor will not turn on with the hopper
removed. Ensure the shutoff knob is in the open position.
Macro/micro grind size adjustment:
The Macro adjustment moves from coarse (31) to fine (1).
With the grinder running, turn the knob to the right to move
from coarse to fine. Espresso: start at 9E Manual brew: start
at 20E. The micro adjust is the bottom ring, from finer (A) to
Coarser (I). Turn to the right to move from coarse to fine. The
micro adjust is stepless with guidelines for repeatability.
Convertible device holder:
The black arms that hold the grounds bin can also be used
to hold most popular brewing devices such as V60, Kalita
Wave, Clever, and Able Kone. To convert the arms to hold a
portafilter, push in on the right arm and swing it down and
to the left. To convert the arms to hold the grounds bin or
other brewing devices, push in on the right arm and rotate
to the right and up. The left arm will automatically move into
WARNING: The Sette grinds at a very high speed, be careful not to overfill your portafilter or
bin! If a mound of coffee backs up into the chute it will clog the grinder.
Time Based Grinding Operation:
Place the portafilter or the grounds bin in the grinder. Press a
preset button (1,2,3). The screen will show the corresponding
programmed grind time in seconds. Press Start (>ll) button
to begin grinding. While grinding, the screen will count UP
the seconds and stop when the preset time is reached.
When the screen reaches the preset time, the motor will stop
and the display will reset again to the programmed time.
For manual quantities of ground coffee, press and hold the
START button until you obtain the desired amount of coffee,
then release the START button, the grinder will then stop with
the screen showing the total amount of seconds run. To get
out of manual mode, press STOP.
SETTE™ 270 QUICK START GUIDE
Coarse
31 29 27 25 23 21 19
Finer
A B C D
position. In the center, above the arms, is a hook for holding
the lip of your portafilter, providing stability. This hook can
be rotated out of the way by pressing down on the hook
and then rotating it left or right. To return to center position
simply press down and rotate it back to center.
Adjusting the portafilter hook:
When grinding directly into a portafilter, you must first
convert the arms to portafilter mode and swing the hook to
the front. The hook is designed to support the top lip of your
portafilter. It is imperative that your hook is adjusted so that
your portafilter sits level. To adjust the hook, loosen the 2mm
hex screw that sits below the hook, adjust portafilter hook up
or down, and tighten screw once in the proper position.
Fine
17 15 13 11 9 7 5 1 3
Coarser
E F G H I
Rev 11/20/2016 (v7)
