Device Settings Tab Description

Many of the tabs in the Properties windows of the printer are controlled by Windows. However, the Device
Settings tab is for specifying printer configuration-related settings and is part of the printer driver.
The Device Settings tab allows you to specify settings related to the printer unit.
Roll Unit
There will be a checkmark here if the lower level roll unit is attached.
Note
• Where the roll unit set in the winding device is attached, this checkmark will be removed.
Automatically switch paper sources (paper size priority)
Prints after automatically switching between roll paper 1 and roll paper 2 depending on the size of
the paper to be printed.
This will save paper as the roll paper that will give the smallest margin when printing is
automatically selected.
Important
• Make sure that the same type of paper is used in the upper level and lower level of the printer.
Printing is not possible when different types of paper are used.
• Be sure to click Acquire Status from the Device Settings tab to get information on the roll
paper width. You may not be able to print correctly if the roll paper width is not correctly set.
• Be sure to select Roll Paper (Auto) as Paper Source from Page Setup. This function cannot
be used unless Roll Paper (Auto) is selected.
Roll Paper Width 1
Sets the width of the roll paper loaded in the upper level (Roll 1).
Roll Paper Width 2
Sets the width of the roll paper loaded in the lower level (Roll 2).
