- Page 1 INSTRUCTION MANUAL Portable Cut-Off M2400 012155 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model M2400 Wheel diameter 355 mm Hole diameter 25.4 mm No load speed (min 3,800 Dimensions (L x W x H) 500 mm x 280 mm x 620 mm Net weight 15.7 kg Safety class • Due to our continuing program of research and development, the specifications herein are subject to change without notice. -
Page 3: Additional Safety Rules For Tool
When operating a power tool outdoors, use an 20. Disconnect the plug from the power source extension cord suitable for outdoor use. Use of and/or the battery pack from the power tool a cord suitable for outdoor use reduces the risk of before making any adjustments, changing electric shock. -
Page 4: Installation
Keep guards in place and in working order. FUNCTIONAL DESCRIPTION Hold the handle firmly. Keep hands away from rotating parts. 10. Make sure the wheel is not contacting the CAUTION: work-piece before the switch is turned on. Always be sure that the tool is switched off and •... - Page 5 Tighten the hex bolts securely. At this time, make Interval between vise and guide plate sure that the guide rule does not move. Check the angle again. 1. Socket wrench 2. Guide plate CAUTION: 3. Move Never perform right miter cuts when the guide plate 4.
-
Page 6: Securing Workpiece
If you use a spacer block which is slightly narrower than Securing workpiece the workpiece as shown in the figure, you can also utilize the wheel economically when worn down the wheel. 1. Vise plate 2. Vise nut 1. Diameter of 3. -
Page 7: Replacing Carbon Brushes
012059 To maintain product SAFETY and RELIABILITY, repairs, Carrying tool any other maintenance or adjustment should be performed by Makita Authorized Service Centers, always using Makita replacement parts. 012086 Fold down the tool head to the position where you can attach the chain to the hook on the handle. - Page 8 Makita Corporation Anjo, Aichi, Japan www.makita.com 885414-937...
