700 Series Managed Switch User's Guide for Software v2.1
Switchport
The
command lets you configure VLAN access mode of this particular port.
switchport
•
VLAN
syntax
FSM726(config-if)# switchport access vlan [tagged <VLAN Membership> | untagged <VLAN
membership>]
Where:
tagged <VLAN Membership>
Membership ranges from 1-4094
untagged <VLAN Membership>
Membership ranges from 1-4094
For example, suppose this particular port belongs in VLAN 64 and 32. You wish to configure it so
that it operates in tagged mode in VLAN 64, but in untagged mode in VLAN 32, the command to
do so would be:
FSM726(config-if)# switchport access vlan tagged 64
FSM726(config-if)# swtichport access vlan untagged 32
•
Native
All untagged packets entering the switch will by default be tagged with the ID specified by the
port's PVID. This command allows you to specify the PVID for each port. The PVID values
ranges from 1-4094. Following industry standards, PVID 1 is the default PVID
Syntax
FSM726(config-if)# switchport access native <PVID value>
where
= the PVID value assigned for this particular port.
<PVID Value>
6-18
= setting the VLAN membership to tagged mode. VLAN
= setting the VLAN membership to untagged mode. VLAN
SM-10004-02
Command Line Interface
