User Manual
GO-DSL-N150
(Unspecified Bit Rate). These QoS types are all controlled by the parameters
specified below, including PCR, SCR and MBS.
PCR: Peak Cell Rate.
SCR: Sustained Cell Rate.
MBS: Maximum Burst Size.
Internet :: Encapsulation
Dynamic IP: Select this option if your ISP provides you an IP address
automatically. This option is typically used for Cable services. Please enter the
Dynamic IP information accordingly.
Static IP: Select this option to set static IP information. You will need to enter in
the Connection type, IP address, subnet mask, and gateway address, provided
to you by your ISP. Each IP address entered in the fields must be in the
appropriate IP form, which are four IP octets separated by a dot (x.x.x.x). The
Router will not accept the IP address if it is not in this format.
PPPoA/PPPoE: Select this option if your ISP requires you to use a PPPoE
connection. This option is typically used for DSL services. Select Dynamic
PPPoE to obtain an IP address automatically for your PPPoE connection. Select
Static PPPoE to use a static IP address for your PPPoE connection. Please enter
the information accordingly.
Bridge Mode: The modem can be configured to act as a bridging device
between your LAN and your ISP. Bridges are devices that enable two or more
networks to communicate as if they are two segments of the same physical LAN.
Please set the Connection type.
Internet :: PPPoE/PPPoA
Select this option if your ISP requires you to use a PPPoE connection. This
option is typically used for DSL services. Select Dynamic PPPoE to obtain an IP
address automatically for your PPPoE connection. Select Static PPPoE to use a
static IP address for your PPPoE connection. Please enter the information
accordingly.
Username: Enter your username for your PPPoE/PPPoA connection.
Password: Enter your password for your PPPoE/PPPoA connection
Encapsulation: For both PPPoE/PPPoA connection, you need to specify the
type of Multiplexing, either LLC or VC Mux.
55
