The following table describes the parameters of this page:
Field
VLAN Index
Active
VLAN ID
ATM VCs
Ethernet
Wireless
LAN
Save
Delete
Cancel
Define the VLAN Group ID (1 to 8).
Choose to active or deactive the VLAN group.
Input a VLAN ID for the Group.
Select what ATM VCs (0 to 7) will join the VLAN group.
Also choose whether it will be tagged or untagged.
Select what Ethernet ports (1 to 4) will join the VLAN
group. Also Choose whether it will be tagged or untagged.
Choose to assign the Wirless LAN to the VLAN group.
Click it to save the settings.
Click it to delete the current group setting.
Cancel the current group setting.
