VPN Settings

Example of a Manual Policy

The following example shows settings on the IPSEC CONFIGURATION page for creating a
VPN tunnel between two routers:
Router 1: Option=10.0.0.1 LAN=192.168.10.1 Subnet=255.255.255.0
Policy Name: manualVPN
Policy Type: Manual Policy
Local Gateway: Option
Remote Endpoint: 10.0.0.2
Local IP: Subnet 192.168.10.0 255.255.255.0
Remote IP: Subnet 192.168.20.0 255.255.255.0
SPI-Incoming: 0x1111
Encryption Algorithm: DES
Key-In: 11112222
Key-Out: 33334444
SPI-Outgoing: 0x2222
Integrity Algorithm: MD5
Key-In: 1122334444332211
Key-Out: 5566778888776655
Router 2: Option=10.0.0.2 LAN=192.168.20.1 Subnet=255.255.255.0
Policy Name: manualVPN
Policy Type: Manual Policy
Local Gateway: Option
Remote Endpoint: 10.0.0.1
Local IP: Subnet 192.168.20.0 255.255.255.0
Remote IP: Subnet 192.168.20.0 255.255.255.0
SPI-Incoming: 0x2222
Encryption Algorithm: DES
Key-In: 33334444
Key-Out: 11112222
SPI-Outgoing: 0x1111
Integrity Algorithm: MD5
Key-In: 5566778888776655
Key-Out: 1122334444332211
103
