Displaying the diagnostic buffer
1. Click the "Messages and Logs" entry in the navigation.
2. Click the "Diagbuffer" tab.
Figure 6-33
Click the Refresh button to update the display of the diagnostic buffer.
Drive functions
Function Manual, (FH1), 01/2013, 6SL3097-4AB00-0BP3
The diagnostic buffer is then displayed on the "Diagbuffer" tab.
Displaying the diagnostic buffer
The following information is displayed:
Column Explanation
No. Number of the event
Time Time of the event
Date Date of the event
Event Displays the event as text
