Set Equipment Clock and Synchronization
4. Assign the appropriate value to each parameter:
Figure 9-7 Step 1 PTP Mode Setting Option Window
Parameter
NOTE
PTP Mode
PTP Profile
Transport Mode
Communication
Mode
Multicast Type
5. When completed, click the
6.
iPASOLINK EX Advanced: S
Table 9-2 PTP Mode Setting Parameters
Value
Boundary Clock (BC)
Transparent Clock
(TC)
Disable
IEEE 1588v2
G.8275.1
PTP over Ethernet
Multicast
Non Forwardable
Forwardable
NOTE: PTP function (TC mode and BC mode) is supported for 1Gbps or
10Gbps transmission.
Warning
dialog box appears. Click the
N
S
ET
ETWORK AND
YSTEM
Description
Enables the PTP Mode (Boundary Clock mode) settings..
Enables to PTP Mode (Transparent Clock mode) settings.
Disables the PTP Mode settings.
Sets the PTP Profile to IEEE 1588v2.
Sets the PTP Profile to G.8275.1.
Transport Mode is fixed to PTP over Ethernet, which
operates in the mode according to the IEEE1588-2008
Annex F.
Communication Mode is fixed to Multicast traffic, which
operates in the mode according to the IEEE 1588-2008
Annex F.
Select the Multicast Destination Address to use, which
should be associated with that of the opposing site
equipment.
Next
button.
OK
P
ROVISIONING
button of the dialog box to proceed.
9-7
GGS-000547-01E
