Chapter 4
Sensor Sensor
Type Number
01
02
21
22
23
24
25
26
27
28
29
2A
02
07
08
0A
0B
0C
0D
0E
0F
10
11
12
13
15
16
17
18
19
1A
41
42
43
44
45
46
47
48
Sensor Name
Backplane (HSC TeeDock) Temperature
HSC SCSI Backplane Temperature
Processor 0 Core Temperature
Processor 1 Core Temperature
Processor 2 Core Temperature
Processor 3 Core Temperature
Upper Memory Board Temperature
Lower Memory Board Temperature
Sideplane Temperature
I/O Board Temperature
Processor Board Temperature 1
Processor Board Temperature 2
Voltage
Baseboard +1.5 Volt
Baseboard +1.8 Volt
Baseboard +2.8 Volt
Baseboard +3.3 Volt
Baseboard +3.3 Volt SB
Baseboard +5 Volt
Baseboard +5 Volt SB
Baseboard +12 Volt
Baseboard –12 Volt
Processor Board +1.5 Volt
Processor Board +1.8 Volt
Processor Board +3.3 Volt
SCSI TERM Volt 00
SCSI TERM Volt 01
SCSI TERM Volt 02
SCSI TERM Volt 10
SCSI TERM Volt 11
SCSI TERM Volt 12
Processor 0 Power Good
Processor 1 Power Good
Processor 2 Power Good
Processor 3 Power Good
Processor Board 1.5 Volt Power Good
Processor Board 1.5 Volt FOK
Processor Board 1.8 Volt Power Good
Processor Board 1.8 Volt FOK
Diagnostics
36
