Cub Cadet Sc2450 Part List Manual page 89

Sc Series
REF
NO.
PART NUMBER
1 CY-194990-22140
2 CY-1A7880-27500
3 CY-1A7880-27560
4 CY-1A7880-27580
5 CY-22117-100000
6 CY-22157-100000
7 CY-22242-000100
8 CY-22242-000300
9 CY-24104-060004
10 CY-26106-080252
11 CY-26716-080002
12 CY-198200-27810
89
Fig. 47 - Range Shift Lever
DESCRIPTION
NUT W/WASHER 8
LEVER CMP,RANGE
ARM,RANGE
SPRING
WASHER 10
WASHER 10
CIRCLIP 10
CIRCLIP 30
BALL BEARING
BOLT M 8X 25 PLATED
NUT M 8
KNOB, ORANGE
Copyright 2009 Cub Cadet Yanmar LLC
Sc2450
QTY
2
1
1
1
1
1
1
1
1
1
1
1
