Cub Cadet Sc2450 Part List Manual page 76

Sc Series
REF
NO.
PART NUMBER
1 CY-178080-06200
2 CY-187K06-24540
3 CY-194065-27270
4 CY-168H60-29840
5 CY-187K06-24550
6 CY-192157-24560
7 CY-187K06-24570
8 CY-187K06-24600
9 CY-192157-24850
10 CY-168H60-29390
11 CY-168H60-29400
12 CY-168H60-29411
13 CY-1A7130-29420
14 CY-187K06-29460
15 CY-168HK0-29620
16 CY-22242-000160
17 CY-22252-000420
18 CY-22312-060100
19 CY-26106-080302
20 CY-26106-101052
21 CY-26776-100002
76
Fig. 36 - Motor Case
DESCRIPTION
THRUST METAL(DDR16
SIDE COVER CMP
SEAL TC16 26 6, OIL
BUSH 16X24X30
MOTOR CASE K93
PACKING, MOTOR CASE
PAKING (SIDE COVER
SECOND LEVER CMP
PIN 12X22,KNOCK
WASHER 17X32X1
SHIFT BLOCK
CONTROL ARM
SET SCREW 10X20
SWASH PLATE
PLATE, THRUST
CIRCLIP 16
CIRCLIP 42
PARALLEL PIN, M6X10
BOLT M 8X 30 PLATED
BOLT M10X105 PLATED
LOCK NUT M10 PLATED
Copyright 2009 Cub Cadet Yanmar LLC
Sc2450
QTY
2
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
4
1
1
