02、 Introduction To Standard Receivers - Microzone 8B-MINI Product Manual

DIGITAL PROPORTIONAL R/C
SYSTEM
INTRODUCTION TO STANDARD RECEIVERS
FM button
After the receiver is powered
on, press the frequency pairing
button and turn on the power
switch of the remote control,
the frequency pairing is
successful
8 PWM signal
1 SBUS signal
www.microzone.cn
MC9002
(-)negative (S)signal
electrode
(+)positive
electrode
2.4GHz
External input power supply
For indoor testing
External antenna
(S)signal
(+)positive
electrode
(-)negative
electrode
FHSS
-04-
