LED Light Kit
Greensmaster
Series Mower
Model No. 04293
This product contains a chemical or chemicals known to the State of California to
Important: If you are installing the LED Light Kit on Greensmaster Models 04040, 04041, 04044, and 04045, ensure
that you have installed the LED Light and Wireless Hour Meter Harness Kit for 2012 and After (Model 04295)
before you install the LED light kit.
Note: Determine the left, right, front, and back sides of the machine from the normal operating position.
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
5
6
7
© 2016—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
Flex
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Description
No parts required
No parts required
Left light-bar strap
Flange-head bolt (5/16 x 1-1/4 inches)
Flange locknuts (5/16 inch)
Flange-head bolt (5/16 x 1 inch)
Washer (5/16 inch)
Right light-bar strap
Cable tie
No parts required
Cable tie
2-position rocker switch
No parts required
Register at www.Toro.com.
™
1800/2100 Series and eFlex
WARNING
CALIFORNIA
Qty.
–
–
1
4
6
2
2
1
3
–
3
1
–
Form No. 3399-947 Rev C
®
1800/2100
Installation Instructions
Use
Prepare the machine.
Remove the control-panel cover.
Assemble the light bar to the machine.
Assemble the LED lights to the light bar.
Install the wire harness to the machine.
Install the light switch (machine models
04042, 04043, 04046, and 04047).
Finish the light kit installation.
Original Instructions (EN)
All Rights Reserved *3399-947* C
Printed in the USA
