- Page 1 25 TON VERTICAL/HORIZONTAL LOG SPLITTER MODEL NO. S401625PH Owner’s Manual ASSEMBLY & OPERATING INSTRUCTIONS This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. LS141-826-0412 Rev.
-
Page 2: Table Of Contents
Table of Contents Page(s) Important Safety Information......................... Intended Use ......................... Personal Protective Equipment ....................Safety Decals ........................General Safety ........................Work Area ..........................Preparation of the Log ......................Operation of the Log Splitter ....................Repair and Maintenance Safety ..................... Hydraulic Safety ........................Fire Prevention ........................ -
Page 3: Important Safety Information
BEFORE operating this log splitter, make sure that you wear safety gear such as goggles or safety glasses, steel toed shoes and tight fitting gloves (without loose cuffs or draw strings). Always wear a protective hearing device when operat- ing this log splitter. SAFETY DECALS Make sure that all safety warning decals are in good condition and readable. Always replace missing or defaced decals. Contact SpeeCo at 1-800-525-8322 for replacement decals. PART NUMBER: S52062500 LOCATION: TOP, FRONT END OF TONGUE Page 1... - Page 4 PART NUMBER: S52062200 LOCATION: TOP OF CYLINDER PART NUMBER: S52062300 LOCATION: STRIPPER PLATE, OPERATOR SIDE PART NUMBER: S52062600 LOCATION: STRIPPER PLATE, NON OPERATOR SIDE PART NUMBER: S52062400 LOCATION: HYDRAULIC TANK LOWER TANK, RIGHT CORNER PART NUMBER: S52062100 LOCATION: TOP OF HYDRAULIC CYLINDER Page 2...
-
Page 5: General Safety
GENERAL SAFETY ALWAYS keep the operator’s manual nearby for reference. Reread the manual periodically. ALWAYS keep all bystanders and pets a minimum of 10 feet away from your work area when operating this log splitter. Only the operator is to be near the log splitter during use. NEVER allow adults lacking proper instructions and understanding to operate this log splitter. -
Page 6: Repair And Maintenance Safety
ALWAYS block the wheels to prevent movement of the log splitter while in operation. KNOW how to stop the log splitter and disengage the controls before operating it. NEVER place hands or feet between the log and splitting wedge during forward or reverse stroke as this could result in serious injury or death. -
Page 7: Hydraulic Safety
MAINTENANCE & SAFETY The hydraulic system of your log splitter requires careful inspection along with the mechanical parts. Be sure to replace frayed, kinked, cracked or otherwise damaged hydraulic hoses or hydraulic components. NEVER check for leaks of hydraulic fluid with your hand. Fluid escaping from a small hole can be almost invisible. Escaping fluid under pressure can have sufficient force to penetrate skin causing SERIOUS INJURY or even DEATH. Leaks can be safely detected by passing a piece of cardboard over the suspected leak and looking for discoloration. NEVER remove the cap from the hydraulic tank or reservoir while the log splitter is running. The tank could contain hot oil under pressure which could result in serious injury. -
Page 8: Towing Safety
IMPORTANT NOTE – (spark arrester): As a precautionary measure against possible flying sparks, always take a Class B fire extinguisher with you when operating this log splitter in dry areas. This log splitter is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS NOTE: This log splitter was partially assembled at the factory. Refer to the drawings and parts list should it become necessary to disassemble the unit for repair or replacement of parts. ITEM NO. PART NO. DESCRIPTION QTY. DESCRIPTION QTY. Beam Assembly Beam Lock Assembly Tank Assembly Tire and Wheel Tongue Assembly STEP 1: Remove all the components from the shipping container. Inspect each piece for shipping damage. If any part is damaged, contact your dealer or delivering carrier. - Page 10 STEP 3: Attach the tongue assembly (5) to the tank assembly (1) using two 1/2” NC x 4-1/2” hex cap bolts (2), two 1/2” lock washers (3) and two 1/2” hex nuts (4). Tighten. ITEM NO. DESCRIPTION QTY. Tank Assembly 1/2”...
- Page 11 STEP 5: Connect the end of the 1/2” ID x 38” hydraulic pressure hose (1) coming from the fitting on the pump to the fitting on the valve. See illustrations below. STEP 6: Slide one hose clamp on the end of the 3/4” x 56” hydraulic return hose (2) that comes from the fitting on the filter. Then connect the hose to the fitting on the valve. Tighten hose clamp. See illustrations below. Area of DETAIL A Detail SCALE 1:3 ITEM NO. DESCRIPTION QTY. 1/2” X 38” Pressure Hose 3/4” x 56” Return Hose Worm Gear Clamp STEP 7: Attach the latch (3) to the bottom side of the beam as shown in the diagram using the two 1/2” x 1-1/4” Grade 5 hex cap bolts (4), the two 1/2”...
-
Page 12: Replacement Parts
REPLACEMENT PARTS TANK/ENGINE ASSEMBLY BREAKDOWN ITEM NO. PART NO. DESCRIPTION QTY. 5/16” Flat Washer 5/16”-18UNC Nylock Nut 5/16” x 1-1/2” GR 5 Bolt S40118800 Tank S390604B0 Filter Base S390601A0 Filter Element S39034900 3/4” Hex Nipple S39038300 Straight Fitting, 3/4” NPT to 1 3/4”... - Page 13 BEAM ASSEMBLY BREAKDOWN ITEM NO. PART NO. DESCRIPTION QTY. 1/2” Hex Nut 1/2” Regular Lock Washer 1/2” x 3-1/4” Hex Bolt S390119B0 4.5” x 24” Hydraulic Cylinder S39032000 3/4” NPT x 3/4” Tube S39034300 1/2” NPT Nipple S39034600 1/2” Steel Tubing S39034700 1/2”...
-
Page 14: Operating Instructions
OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dan- gerous if assembled or used improperly. -
Page 15: Operation
TURN FUEL SHUT OFF VALVE TO THE “OFF” POSITION PRIOR TO TOWING. FAILURE TO DO SO MAY RESULT IN CAUTION: FLOODING THE ENGINE. NOTE: The engine maximum governed speed is preset at the factory at 3600 RPM no load speed. When splitting wood the throttle should be set at the maximum speed to develop the horsepower required for the pump. -
Page 16: Warranty And Service Information
IMPORTANT NOTICE We, the manufacturer, reserve the right to change the product and/or specifications in this manual without notification. The manual is for information usage only and the pictures and drawings depicted herein are for reference only. NOTES Warranty Repair and Service Do not return this product to the store for warranty issues or repair. Call 1-800-525-8322 for the location of the nearest service center. -
Page 17: Specifications
SPECIFICATIONS Engine Honda GC 190 Pump Two-Stage, 11 gpm Cylinder 4-1/2 in. Diameter x 24 in. Stroke Valve Auto-Return Maximum Splitting Force 25 Tons Maximum Log Length 26 in. Cycle Time* 16 Seconds Wheels 4.80 x 8 in. Wedge 7 in. High with Spreader Wings Beam Size 6 in. x 9 in. with Built-In Log Cradle Hydraulic Capacity...
