SpeeCo splitMaster S400197N0 Owner's Manual

3-point hitch vertical/horizontal log splitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

ASSEMBLY & OPERATING INSTRUCTIONS
WARNING:
splitter. Follow the safety instructions in the manual and in decals attached
to the product. Failure to do so could result in serious injury or death.
LS47-631-0712
Rev. 4
VERTICAL/HORIZONTAL LOG SPLITTER
MODEL NO. S400197N0
Owner's Manual
All operators must read this manual before operating this log
3-POINT HITCH
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the splitMaster S400197N0 and is the answer not in the manual?

Questions and answers

Related Manuals for SpeeCo splitMaster S400197N0

Summary of Contents for SpeeCo splitMaster S400197N0

  • Page 1 3-POINT HITCH VERTICAL/HORIZONTAL LOG SPLITTER MODEL NO. S400197N0 Owner’s Manual ASSEMBLY & OPERATING INSTRUCTIONS WARNING: All operators must read this manual before operating this log splitter. Follow the safety instructions in the manual and in decals attached to the product. Failure to do so could result in serious injury or death.

  • Page 2: Table Of Contents

    Table of Contents Page(s) Important Safety Information......................... Intended Use ......................... Personal Protective Equipment ....................General Safety ........................Safety Decals ........................Preparation of the Log ......................Work Area ........................... Operation of the Log Splitter ....................Repair and Maintenance Safety ..................... Hydraulic Safety ........................Assembly Instructions ........................

  • Page 3: Important Safety Information

    WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly.

  • Page 4: Safety Decals

    SAFETY DECALS Make sure that all safety warning decals are in good condition and readable. Always replace missing or defaced decals. Write us or call 1-800-525-8322 and they will be sent to you at no charge. PART NUMBER: S52062200 PART NUMBER: S52062300 LOCATION: TOP OF CYLINDER LOCATION: STRIPPER PLATE, OPERATOR SIDE...

  • Page 5: Preparation Of The Log

    PREPARATION OF THE LOG Both ends of the log should be cut as square as possible to help prevent the log from riding out of the splitter during operation. Do not split logs greater than 26 in. in length. EVER WORK AREA NEVER operate the log splitter on slippery, wet, muddy or icy ground.

  • Page 6: Repair And Maintenance Safety

    REPAIR AND MAINTENANCE SAFETY NEVER operate your log splitter when it is in poor mechanical condition or in need of repair. Periodically check that all nuts, bolts, screws, hydraulic fittings and hose clamps are tightened. NEVER alter your log splitter in any manner such as adding a rope or extension to the control lever or adding to the width or height of the wedge.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS NOTE: This log splitter was partially assembled at the factory. Refer to the drawing and parts list should it become necessary to disassemble the unit for repair or replacement of parts. STEP 1: Remove all the components from the crate. Inspect each piece for shipping damage. If any part is damaged, contact your dealer or delivering carrier.

  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly.

  • Page 9: Parts List For 3- Point Hitch Log Splitter

    PARTS BREAKDOWN FOR S400197N0 REFERENCE PART DESCRIPTION NUMBER NUMBER NUMBER REQUIRED 3-Point Hitch Vertical/Horizontal Log Splitter Complete S400197N0 3-Point Hitch Vertical/Horizontal Log Splitter Complete S401411R0 Beam (6” x 9”) for 400197N0 S40141700 Wedge O/L 1/2 in. NC x 3 in. Hex Cap Screw (Grade 5) O/L 1/2 in. Lockwasher O/L 1/2 in. NC Hex Nut S390118B0 4 in. x 24 in. Hydraulic Cylinder O/L Clip Pin S07073100 Cylinder Pin with Clips S39030200 Swivel Elbow S39026300 1/2” x 27” Hydraulic Pressure Hose S39034300 1/2 in. - 1/2 in. Hex Nipple...

  • Page 10: Parts Breakdown Illustration For 3-Point Hitch Log Splitter

    Page 8...

  • Page 11: Specifications

    SPECIFICATIONS Tractor Categories 1 and 2 Maximum Splitting Force Depends on tractor* Cycle Time Depends on tractor* Maximum Log Length 26” Cylinder 4” diameter x 24” stroke Valve Auto-return Beam Size 6” x 9” Wedge 7” high with spreader wings Hitch Tractor 3-point Height 42”...
