Important media printer adjustments

Important media printer adjustments
Introduction
In the table below some important media printer adjustments that are available in the Settings
Editor are described.
NOTE
The complete media adjustments are described in the Settings editor user manual.
General
Item
Saddle stitch po-
sition adjustment
(mm)
Saddle stitch fold
position adjust-
ment (mm)
Punch hole posi-
tion adjustment
(mm)
Saddle fold posi-
tion adjustment
(mm)
138 Chapter 11 - Appendix
Setting Objective
Range: -2.00 to Move the stitch position to-
+2.00 mm, step wards the intended centre
0,25 mm., default of the booklet. If necessary,
0.0 mm perform the 'Saddle stitch
fold position adjustment' to
move the fold towards the
intended centre too.
Range: -2.00 to When the saddle stitch
+2.00 mm, step function of the Saddle Fin-
0,25 mm., default isher is used, the value is
0.0 mm changed if the fold place-
ment is not exactly on the
centre of the paper.
Range: -2.0 to Use this function when the
+2.0 mm, step punch hole position is off-
0.25 mm., default set due to the paper type
0.0 mm used.
Range: -2.00 to When the saddle fold func-
+2.00 mm, step tion of the Saddle Finisher
0.25 mm, default is used, the value is
0.0 mm changed if the fold place-
ment is not exactly on the
centre of the paper.
When/How
Change the value when the
saddle stitch position is
slightly offset from the pa-
per center.
- Increase: the saddle stitch
position is shifted to the
right of the printing side.
- Decrease: the saddle
stitch position is shifted to
the left of the printing side.
- Increase the setting value
to shift the fold placement
to the right of the printing
surface.
- Decrease the setting val-
ue to shift the fold place-
ment to the left of the print-
ing surface
- Increased values: the
punch hole position is shif-
ted to the bottom.
- Decreased values: the
punch hole position is shif-
ted to the top.
- Increase the setting value
to shift the fold placement
to the left. - Decrease the
setting value to shift the
fold placement to the right.
