G 1xxx/G 2xxx
4.2

Basket Guide Removal

1. Open the door.
2. Remove the top basket.
Warning!
The basket guide must not be levered off in the area of the bolts (see Figure
040-4). This could result in damage to the cabinet walls.
3. Slide out the basket guide (Figure 040-4, Item 1) until the clip (Figure
040-5, Item 1) between the bolt on the cabinet wall and the basket guide
is visible.

Figure 040-4: Basket Guide

Figure 040-5: Clip with Bolt

4. Insert a small screwdriver under the clip between the bolt on the cabinet
73
