Communications configuring
SNV=TRUE (message numbers available)
STM=TRUE (message text available)
SSF=FALSE (HEX format)
Contents
Spontaneous ID
Sequence number
Message type descrip.
Message type
Prefix
Suffix
Measured value scaling
factor
Measured value
Measured value data
type
Measured value
dimensions text
Message instant
Message text
Table 3-79 Hexadecimal format with number and text
SNV=FALSE (message numbers not available)
STM=TRUE (message text available)
SSF=FALSE (HEX format)
Contents
Spontaneous ID
Sequence number
Message type descrip.
Message type
Measured value scaling
factor
Measured value
Measured value data
type
Measured value
dimensions text
Message instant
Message text
Table 3-80 Hexadecimal text without number with text
3-250
Message structure
(max. 92 bytes)
Unsigned8
Unsigned8
1 Octet
1 Octet
Unsigned16
Unsigned16
Floating-Point
4 Octets
2 Octets
8 characters
Time and date
max. 60 characters
Message structure
(max. 88 bytes)
Unsigned8
Unsigned8
1 Octet
1 Octet
Floating-Point
4 Octets
2 Octets
8 characters
Time and date
max. 60 characters
System- and communication configuring D7-SYS - SIMADYN D
Net data structure Data format
1. variable unit Unsigned8
2. variable unit Octet-String
3. variable unit Unsigned16
4. variable unit Floating-Point
5. variable unit Octet-String
6. variable unit Visible-String
7. variable unit Time and
Date
8. variable unit Visible-String
Net data structure Data format
1. variable unit Unsigned8
2. variable unit Octet-String
3. variable unit Floating-Point
4. variable unit Octet-String
5. variable unit Visible-String
6. variable unit Time and
Date
7. variable unit Visible-String
No. of data
2
2
2
1
6
8
1
60
No. of data
2
2
1
6
8
1
60
