Figure 4-5
10.Select the row of holes. The selection of the row of holes depends on the yoke width of
the actuator. Select the row of holes in such a way that the carrier pin
pick-up bracket
the clamping pieces
11.Keep the positioner and the fastening bracket on the actuator. Ensure that the carrier pin
④
12.Tighten the pick-up bracket
13.Fasten the positioner on the yoke. Use the installation parts suitable for the
corresponding actuator.
Note
Height adjustment of the positioner
When you fasten the positioner on the yoke, the following applies to its height adjustment:
1. Set the height of the positioner in such a way that the horizontal lever position is near
2. Orient yourself by the lever scale of the actuator.
3. If symmetrical mounting is not possible, you must always ensure that the horizontal
SIPART PS2 with and without HART
Operating Instructions, 09/2014, A5E00074631-12
Positioner in the flameproof enclosure, base plate
②
near the spindle. Ensure that the pick-up bracket
③
.
is guided inside the pick-up bracket
the center of the stroke.
lever position is maintained within the range of stroke.
②
.
②
.
Installing/mounting
4.2 Mounting the linear actuator
④
meshes with the
②
does not touch
