Corrected System Performance (HP 8719/20ET)

The specifications in this section apply for measurements made using 10 Hz IF bandwidth,
no averaging, and at an environmental temperature of 23 ±3 °C, with less than 1 °C
deviation from the calibration temperature. Assumes that an isolation calibration was
performed with an averaging factor of 8.
Table 2-1 System Dynamic Range, All Device Connector Types
HP 8719/20ET, All Options, All Cal Kits, All Cables, 10 Hz IF BW
Description
System Transmission Dynamic Range
50 MHz to 840 MHz
840 MHz to 8 GHz
8 GHz to 20 GHz
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
Table 2-2 System Dynamic Range, All Device Connector Types
HP 8722ET, All Options, All Cal Kits, All Cables, 10 Hz IF BW
Description
System Transmission Dynamic Range
50 MHz to 840 MHz
840 MHz to 8 GHz
8 GHz to 20 GHz
20 GHz to 40 GHz
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
HP 8719/20/22ET Specifications and Characteristics
Corrected System Performance (HP 8719/20ET)
Specification
a
102 dB
104 dB
104 dB
Specification
a
98 dB
102 dB
100 dB
89 dB
Supplemental
Information
Supplemental
Information
