HP 8719/20/22ES Specifications and Characteristics
Instrument Specifications

General Information

Table 1-36 General Information
HP 8719/20/22ES General Information
Description
Display Range
Magnitude
Phase
Polar
Display Resolution
Magnitude
Phase
Reference Value Range
Magnitude
Phase
Reference Level Resolution
Magnitude
Phase
Marker Resolution
Magnitude
Phase
Polar
1-40
Specification
±200 dB (at 20 dB/div), max
±180°, max
10 pico units, min
1000 units, max
0.001 dB/div, min
0.01°/div, min
±500 dB, max
±360 °, max
0.001 dB, min
°
0.01
, min
0.001 dB, min
°
0.01
, min
0.01 mUnit, min; 0.01, min
Supplemental Information
