Test Port Input

Table 1-30 Test Port Input
HP 8719ES/20ES/22ES Test Port Input
Description
Frequency Range
HP 8719ES
HP 8720ES
HP 8722ES
Frequency Response (A, B, R)
Channel R
0.05 to 20.05 GHz
20.05 to 32 GHz
32 to 40 GHz
Channels A and B
50 to 500 MHz
0.5 to 20 GHz
20 to 32 GHz
32 to 40 GHz
Impedance
Standard
Return Loss
Standard
Maximum Input Level
Standard
Compression
Damage Level
Standard
Option 012
test port
direct sampler access
a. Maximum level at which no test port overload messages are seen.
Specification
0.05 to 13.51 GHz
0.05 to 20.05 GHz
0.05 to 40.05 GHz
a
+10 dBm
HP 8719/20/22ES Specifications and Characteristics
Supplemental Information
±1.5 dB, char.
±2.5 dB, char.
+2.5 dB to −6 dB, char.
+2.5 dB to −28 dB, char.
±2.5 dB, char.
±3 dB, char.
+3 dB to −6 dB, char.
50 Ω, nominal.
See uncorrected load match
chart.
See dynamic accuracy chart.
+30 dBm or > 40 Vdc, typ.
+30 dBm or > 40 Vdc, typ.
+26 dBm or > 0 Vdc, typ.
Instrument Specifications
1-33
