STM32F205xx, STM32F207xx, STM32F215xx and STM32F217xx

Introduction

This reference manual targets application developers. It provides complete information on

how to use the STM32F205xx, STM32F207xx, STM32F215xx and STM32F217xx

microcontroller memory and peripherals. The STM32F205xx, STM32F207xx,

STM32F215xx and STM32F217xx will be referred to as STM32F20x and STM32F21x

throughout the document, unless otherwise specified.

The STM32F20x and STM32F21x constitute a family of microcontrollers with different

memory sizes, packages and peripherals.

For ordering information, mechanical and electrical device characteristics, please refer to

the STM32F20x and STM32F21x datasheets.

For information on programming, erasing and protection of the internal Flash memory

please refer to the STM32F20x and STM32F21x Flash programming manual.

For information on the Arm

Reference Manual.

Related documents

Available from www.arm.com:

®

• Cortex

Available from your STMicroelectronics sales office:

• STM32F20x and STM32F21x datasheets

• STM32F20x and STM32F21x Flash programming manual

®

• Cortex

2018

®

Cortex

-M3 Technical Reference Manual, available from http://infocenter.arm.com

-M3 programming manual (PM0056)

Reference manual

advanced Arm-based 32-bit MCUs

®

-M3 core, please refer to the Cortex

RM0033 Rev 8

RM0033

®

-M3 Technical

1/1378

www.st.com

1

Table of Contents
