Part 1: Facsimile

Special Function Buttons

FUNCTION button
Use this button to enter user information, to run the MultiPASS C5OOO's
self-cleaning process, check the nozzles, or to print faxes stored in the
CARTRIDGE button
Press this button to release the MultiPASS C5OOO's BJ cartridge holder to
its center position for installing or replacing the cartridge. (Press again
after installing the cartridge to return the cartridge holder back to its
home position.)
RESUME button
Press this button when you want to form-feed paper when printing
Arrow buttons (<, >) 1 and 2
Use these buttons to scroll through menu selections or to move the
cursor when registering data.
PRINTER RESET button 3
Press this button to reset the MultiPASS CSOOO if your PC crashes. This
will maintain all the faxes currently in memory. Do not unplug the

Figure l-7 Operation Panel (3)

1-16
