Canon MultiPASS C5000 Service Manual page 144

Part 1: Facsimile
1. sssw
SW12 (Switch 12: Report frame setting)
Bit
0
1
2
3
4
5
6
7
[Bit 0]
Select whether to draw a frame for printing a report or list.
[Bit l]
If a frame is drawn for printing a report or list, either a solid line or a dashed line can
be selected.
2. NUMERIC PARAM.
N o . _
12
[Parameter 121
When the machinc receives a fax in printer mode, it will automatically switch to fax
mode after a specific period of time (as spcciiicd using the paramctcr setting x10 sec.)
for automatic output of the received image -as long as it is not suffering from an error
mode after generating the received image.
Specifying "0" to the parameter will disablr the automatic switch-over (it does not
mean 0 sec.)
3. INK ABSORBER CAPA
This switch allows the waste ink capacity stored in the SCNT board to be checked or entered.
[SUCTION]
This allows the waste ink capacity for the ink absorbed during cleaning to be checked
or entered.
100 (%b).
NOTE
Function
frame lines
Report
Report frame line types
Not used
Not used
Not used
Not used
Not used
Not used
Function
PRINTER mode + FAX mode automatic
switch-over time in fax reception
The ink absorber's absorption capacity for the waste ink discharged by the
board, check the waste ink capacity and enter the waste ink capacity into
the new PCNT board.
The various waste ink capacity can be checked with the SYSTEM DUMP
LIST.
1
OFF
Dashed line
Selecting range
0- 127
(126 - 9999: Not used)
3 - 4 2
0
ON
line
Solid
6 60 seconds)
